ECMA-C10807RS Delta Servo Motor 750W L , Torque Nm - 2.39 , RPM - 3000

Price 27400.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

ECMA-C10807RS Delta Servo Motor 750W L , Torque Nm - 2.39 , RPM - 3000 Specification

Sealed Type
Packing seal

Product Type
Servo Motor

Usage & Applications
Industrial Machinerry

Color
Black and Silver

Weight
4 Kilograms (kg)

Warranty
1 Year

Phase
Three Phase

Material
Aluminum

ECMA-C10807RS Delta Servo Motor 750W L , Torque Nm - 2.39 , RPM - 3000 Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About ECMA-C10807RS Delta Servo Motor 750W L , Torque Nm - 2.39 , RPM - 3000

The ECMA-C10807RS is a 750W AC Servo Motor from Delta's ASDA-A2 series, designed for mid-range motion applications requiring higher torque and precision. [1, 2]

The ASD-A2-0721-U is a high-performance 750W AC Servo Drive from Delta's ASDA-A2 series, specifically designed for high-resolution positioning and advanced industrial motion control.

Technical Specifications

Rated Power Output: 750W (0.75 kW)
Input Voltage & Phase: 220V AC, Single-phase / 3-phase
Rated Output Current: 5.10 Arms
Frequency Response: 1 kHz
Encoder Support: 20-bit incremental (1,280,000 pulses/rev) or 17-bit absolute
Communication: RS-232, RS-485, and specialized digital interfaces for the "U" model [1, 2, 3, 4, 5, 6, 7, 8]

Dimensions & Weight (Inches)

This motor uses a larger 80 mm frame size compared to the 200W/400W models. [1, 2]

Dimension	Inches	Millimeters
Width	3.15"	80 mm
Height	3.15"	80 mm
Length (Body Only)	~5.44"	138.3 mm
Total Length (with Shaft)	~6.82"	173.3 mm
Shaft Diameter	0.748"	19 mm
Net Weight	~6.61 lbs	3.0 kg

Note: The shipping weight is typically around 7.5 lbs (3.4 kg). [1, 2]

Function

The ECMA-C10807RS provides powerful, high-resolution motion control: [1, 2, 3]

Precision Actuation: Features a 20-bit incremental encoder providing 1,280,000 pulses per revolution for exceptional positioning accuracy.
Torque Performance: Delivers a steady rated torque of 2.39 Nm, with a peak instantaneous torque capacity of up to 7.16 Nm for demanding starts.
Dynamic Speed: Maintains a rated speed of 3,000 RPM (max 5,000 RPM), ideal for high-speed automated processes.
Harsh Environment Ready: Built with an IP65 rating and a pre-installed oil seal to resist dust and water ingress
