ATV310HU15N4E - ATV310 - 1.5 kW - 2 hp - 380...460 V - 3 phase

Price 11300.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

ATV310HU15N4E - ATV310 - 1.5 kW - 2 hp - 380...460 V - 3 phase Specification

Mounting Type
Vertical wall mounting with a heat sink

Feature
High Torque Delivery

Humidity %
5% to 95%

IP Rating
20

Power Rating
380 V to 460 V

Product Type
VFD

Application
Industrial Machinery

Color
Silver-grey

Weight
1.1 Kilograms (kg)

Usage & Applications
Industrial Machinery

Rated Voltage
380 V to 460 V Volt (V)

Warranty
1 Year

Phase
3 Phase

Input Voltage
380 V to 460 V Volt (V)

Features
Flexible Control Modes

Rated Current
380 V to 460 V Volt (v)

Material
Plastic

ATV310HU15N4E - ATV310 - 1.5 kW - 2 hp - 380...460 V - 3 phase Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About ATV310HU15N4E - ATV310 - 1.5 kW - 2 hp - 380...460 V - 3 phase

ATV310HU15N4E

The

Schneider Electric ATV310HU15N4E

is a 1.5 kW (2 hp) variable speed drive from the Easy Altivar 310 series, optimized for heavy-duty industrial applications with three-phase asynchronous motors

Key Technical Specifications

According to the Schneider Electric Product Page:

Power Rating: 1.5 kW / 2 hp for heavy-duty use.
Voltage Supply: 380 V to 460 V AC, three-phase (50/60 Hz).
Current Ratings:
- Continuous Output Current: 4.1 A at 4 kHz.
- Line Current: 6.5 A at 380 V or 5.4 A at 460 V.
- Maximum Transient Current: 6.2 A for 60 seconds.
Torque Performance: Starting torque of 150% at 3 Hz; transient overtorque up to 170200% of nominal motor torque.

Physical Dimensions & Weight

This model is slightly wider than the lower-powered versions to accommodate the 1.5 kW capacity.

Dimension	Metric	Inches (Approx.)
Height	143 mm	5.63 in
Width	105 mm	4.13 in
Depth	151 mm	5.94 in
Net Weight	1.1 kg	~2.43 lbs

Environmental Resistance (Humidity & Temperature)

Humidity: Supports 5% to 95% relative humidity (non-condensing and without dripping water).
Operating Temperature: -10C to 55C (131F) without derating; up to 60C with current derating of 2.2% per C.
Ruggedness: Features Class 3C3 and 3S2 coated circuit boards for high resistance to chemical and dust pollution.
