ATV340D11N4E - ATV340, 11 kW Heavy Duty, 400 V, 3 phases, Ethernet

Name: ATV340D11N4E - ATV340, 11 kW Heavy Duty, 400 V, 3 phases, Ethernet
Brand: Corbital Enterprise
Price: 58700.0 INR
Availability: InStock

Price 58700.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

ATV340D11N4E - ATV340, 11 kW Heavy Duty, 400 V, 3 phases, Ethernet Specification

Humidity %
5% to 95%

Mounting Type
Vertical wall mounting with a heat sink

Product Type
VFD

Power Rating
380 V to 460 V

Application
Industrial Machinery

Color
Silver-grey

Usage & Applications
Industrial Machinery

Weight
10.2 Kilograms (kg)

Rated Voltage
380 V to 460 V Volt (V)

Warranty
1 Year

Phase
3 Phase

Input Voltage
380 V to 460 V Volt (V)

Material
Plastic

Rated Current
380 V to 460 V Volt (v)

ATV340D11N4E - ATV340, 11 kW Heavy Duty, 400 V, 3 phases, Ethernet Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About ATV340D11N4E - ATV340, 11 kW Heavy Duty, 400 V, 3 phases, Ethernet

The Schneider Electric ATV340D11N4E is the Ethernet-integrated version of the high-performance 11 kW (15 hp) Altivar Machine drive. It is designed for "Smart Factory" environments requiring high-speed data exchange and precision motor control.

Core Technical Specifications

Power Rating:
- Heavy Duty (HD): 11 kW (15 hp) for high-torque industrial machines.
- Normal Duty (ND): 15 kW (20 hp) for variable torque loads (fans/pumps).
Input Voltage: 380V to 480V AC (3-phase).
Nominal Output Current: 24 A (Heavy Duty).
Communication: Embedded dual-port EtherNet/IP and Modbus TCP, plus Modbus RTU serial.
Performance: Ultra-fast 1ms task cycle for near-instantaneous motor response.

Physical Profile

Dimensions (W x H x D): 7.09 x 15.16 x 9.80 inches (180 x 385 x 249 mm).
Weight: 22.49 lb (10.2 kg).
Protection: IP20 rating with 3C3 and 3S3 coated circuit boards for maximum chemical and dust resistance.

Integrated Functions

IoT & Web Server: The "E" version includes a built-in web server for remote monitoring, energy tracking, and diagnostics without special software.
Advanced Safety: Standard includes Safe Torque Off (STO), SS1, and SLS (SIL3/PLe certified).
Motion Control: Supports Closed-Loop control (via optional encoder card) for exact positioning and synchronisation.
