ATV340U30N4E - ATV340, 3 kW Heavy Duty, 400 V, 3 phases, Ethernet

Price 37500.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

ATV340U30N4E - ATV340, 3 kW Heavy Duty, 400 V, 3 phases, Ethernet Specification

Humidity %
5% to 95%

Mounting Type
Vertical wall mounting with a heat sink

IP Rating
20

Product Type
VFD

Power Rating
380 V to 460 V

Application
Industrial Machinery

Color
Silver-grey

Usage & Applications
Industrial Machinery

Rated Voltage
380 V to 460 V Volt (V)

Weight
2.1 Kilograms (kg)

Warranty
1 Year

Phase
3 Phase

Input Voltage
380 V to 460 V Volt (V)

Material
Plastic

Rated Current
380 V to 460 V Volt (v)

ATV340U30N4E - ATV340, 3 kW Heavy Duty, 400 V, 3 phases, Ethernet Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About ATV340U30N4E - ATV340, 3 kW Heavy Duty, 400 V, 3 phases, Ethernet

The Schneider Electric ATV340U30N4E is a high-performance 3 kW (3 hp) Variable Speed Drive from the Altivar Machine ATV340 series. The "E" suffix indicates it is the Ethernet-integrated version, making it ideal for smart manufacturing and Industrial IoT (IIoT) applications.

Core Technical Specifications

Power Rating: 3 kW (3 hp) for Heavy Duty / 4 kW (5 hp) for Normal Duty.
Input Voltage: 380V to 480V AC (3-phase).
Nominal Output Current: 7.2 A (Heavy Duty).
Output Frequency: 0.1 to 599 Hz.
Integrated Safety: Standard includes Safe Torque Off (STO), SS1, and SLS.
Communication: Dual-port EtherNet/IP and Modbus TCP (built-in).

Physical Profile

Dimensions (W x H x D): 3.35 x 10.63 x 9.15 inches (

).
Weight: 4.85 lb (

).
Format: Modular / Cabinet mount with side-by-side mounting capability.

Standout Performance Features

IoT Ready: The embedded Ethernet allows for real-time data sharing and remote diagnostics via a built-in web server.
1ms Task Cycle: Offers extremely fast response times, critical for high-speed indexing or precision material handling.
Closed-Loop Capability: Supports encoder feedback modules for precise position and speed control.
Extreme Durability: Features 3C3 and 3S3 coated boards, providing the highest level of protection against chemical vapors and conductive dust.
