Price 40200.0 INR/ Number

MOQ : 1 Number

ATV340U75N4 - ATV340, 7.5 kW Heavy Duty, 400 V, 3 phases Specification

  • Mounting Type
  • Vertical wall mounting with a heat sink
  • Humidity %
  • 5% to 95%
  • IP Rating
  • 20
  • Power Rating
  • 380 V to 460 V
  • Product Type
  • VFD
  • Application
  • Industrial Machinery
  • Color
  • Silver-grey
  • Rated Voltage
  • 380 V to 460 V Volt (V)
  • Weight
  • 3 Kilograms (kg)
  • Usage & Applications
  • Industrial Machinery
  • Warranty
  • 1 Year
  • Input Voltage
  • 380 V to 460 V Volt (V)
  • Phase
  • 3 Phase
  • Rated Current
  • 380 V to 460 V Volt (v)
  • Material
  • Plastic


ATV340U75N4 - ATV340, 7.5 kW Heavy Duty, 400 V, 3 phases Trade Information

  • Minimum Order Quantity
  • 1 Number
  • Delivery Time
  • 24 Hours


About ATV340U75N4 - ATV340, 7.5 kW Heavy Duty, 400 V, 3 phases

The  is a high-performance 7.5 kW (10 hp) Variable Speed Drive (VSD) from the Altivar Machine ATV340 series. It is specifically engineered for demanding machine applications requiring high dynamic response and robustness in harsh environments.
Core Technical Specifications
  • Power Rating:
    • Heavy Duty (HD): 7.5 kW (10 hp) optimized for high-torque applications.
    • Normal Duty (ND): 11 kW (15 hp) suitable for lower-torque variable loads.
  • Electrical Input: 3-phase, 380 V to 480 V AC (50/60 Hz).
  • Current Rating: Nominal output current of 16.5 A (Heavy Duty).
  • Output Frequency: Adjustable from 0.1 to 599 Hz.
  • Safety Integration: Standard functions include Safe Torque Off (STO), Safe Stop 1 (SS1), and Safely Limited Speed (SLS).
  • Communication: Integrated Modbus RTU serial line as standard.
Physical Profile & Dimensions
  • Dimensions: 4.33 in (W) x 10.63 in (H) x 9.21 in (D) (110 x 270 x 234 mm).
  • Weight: 6.61 lb (3.0 kg).
  • Protection RatingIP20, designed for vertical cabinet mounting.
  • Durability: Class 3C3 and 3S3 coated circuit boards for high resistance to chemical gases and non-conductive dust
