CIMR-VT4A0002BAA - Yaskawa Ac Drive V1000

Name: CIMR-VT4A0002BAA - Yaskawa Ac Drive V1000
Brand: Corbital Enterprise
Price: 9500.0 INR
Availability: InStock

Price 9500.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

CIMR-VT4A0002BAA - Yaskawa Ac Drive V1000 Specification

Frequency
50/60 Hz

Input Current
3.6 A

Output Voltage
Three Phase 200-240V AC

Rated Voltage
200-240V AC

Mounting Type
Panel Mount

Efficiency
>= 95%

Protection Level
IP20

Phase
Single Phase (Input) / Three Phase (Output)

Humidity
95% RH max (non-condensing)

Operating Temperature
-10C to +50C

Main Material
ABS Plastic, Metal

Processing Type
Electric / Variable Frequency Drive

Condition
New

Function
Motor Speed Control

Application
Industrial Automation, Conveyors, Pump Control, Fans, HVAC

Dimension (L*W*H)
128 x 68 x 109 mm

Power Mode
AC

Voltage
200-240V AC

Power Consumption
0.55 kW

Accessories
Instruction Manual, Mounting Hardware

Communication Protocol
RS-485 (Modbus RTU)

Braking Unit
Built-in

Overload Capability
150% for 60 sec

Digital Inputs
7

Analog Outputs
1

Relay Outputs
1

Series
V1000

Analog Inputs
2

Noise Level
Less than 60 dB

Control Method
V/f Control, Open Loop Vector Control

Starting Torque
150% at 3 Hz

Digital Outputs
1

Model Number
CIMR-VT4A0002BAA

Display Type
LED Digital Display

Enclosure Material
Heat Resistant ABS, Metal Frame

Compliance
CE, UL, RoHS

Weight
1.1 kg

CIMR-VT4A0002BAA - Yaskawa Ac Drive V1000 Trade Information

Minimum Order Quantity
1 Number

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About CIMR-VT4A0002BAA - Yaskawa Ac Drive V1000

V1000 Drive Print 1/8 - 25 HP

The V1000 is a world-class compact current vector drive that defines a new world standard. Demands for efficient production and better maintainability are on the rise, spurred by global competition. Yaskawa pays off the promise of being in control with products that make businesses move. The optimum balance of energy input, product output, maintenance risk, and long life is reached with Yaskawa. The V1000 provides a world of power in the palm of your hand!

The V1000 is the flagship drive of the V1000 Family, which also includes the V1000-4X.

Features

Highlights:

Up to 30% smaller than the competition
Current vector control, open loop
RoHS compliance
On-line tuning
Induction motor (IM) or permanent magnet motor (PM) operation
Function Block Diagram (FBD) programming via DriveWorksEZ
Side-by-side installation due to patented hybrid heatsink
Removable terminal block with parameter backup function
One-touch copy function with verify
Super-fast 2 ms scan cycle with dual CPU
EN954-1 Safety Cat. 3, Stop Cat. 0
Increased vibration resistance, from 20 Hz to 50 Hz (0.65G)
1 in 10,000 failure rate
Swing PWM function to decrease noise at low carrier frequencies
Pre-maintenance function
Modbus communication
Cooling fan replacement without tools
MTBF: 28 years
Short Circuit Current Rating (SCCR): 30kA rms symmetrical

Advanced Motor Speed Control

The Yaskawa V1000 AC Drive delivers precise speed regulation using V/f and open loop vector control methods, paired with a built-in braking unit and high starting torque. Its flexibility supports efficiency in automation across fans, pumps, conveyors, and HVAC systems, improving process control and performance.

Robust Design with Versatile Application

Built from heat resistant ABS and a metal frame, the V1000 withstands industrial conditions. The drive operates reliably in temperatures ranging from -10C to +50C and up to 95% RH non-condensing humidity, making it perfect for varied industrial settings in India.

FAQ's of CIMR-VT4A0002BAA - Yaskawa Ac Drive V1000:

Q: How do I install the Yaskawa V1000 AC Drive (CIMR-VT4A0002BAA)?

A: To install, mount the drive on a panel using the included hardware, ensuring adequate ventilation. Connect input power (single-phase 200-240V AC) and output to a three-phase motor. Follow the instruction manual for terminal wiring and safety procedures.

Q: What industrial applications can the V1000 AC Drive be used for?

A: This drive is designed for use in conveyors, pump control, fans, and HVAC systems, offering reliable motor speed control in industrial automation processes.

Q: When should the built-in braking unit be utilized?

A: The integrated braking unit provides rapid motor deceleration and is beneficial during high-speed stops, acceleration, or reversing motions-especially useful in conveyor and pump applications.

Q: Where can I find communication support with this drive?

A: The V1000 supports RS-485 (Modbus RTU), allowing seamless integration into industrial networks for monitoring and control from a central system.

Q: What process parameters can be monitored on the V1000's display?

A: With its LED digital display, users can monitor status indicators, frequency, current, fault codes, and parameter settings, simplifying diagnostics and configuration.

Q: How does the V1000 benefit industrial automation systems?

A: By delivering high efficiency (95%), robust overload capability, and versatile control methods, the V1000 enhances energy savings, precise motor control, and system reliability for industrial settings.
