DVP04DA-H2 - Delta PLC

Name: DVP04DA-H2 - Delta PLC
Brand: Corbital Enterprise
Price: 27500.0 INR
Availability: InStock

Price 27500.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Number

DVP04DA-H2 - Delta PLC Specification

Mounting Type
DIN Rail

Humidity
5% to 95%

Output Voltage
24V DC Volt (V)

Input Current
24V DC

Phase
DC power

Rated Voltage
24V DC Volt (V)

Usage
Industrial Machinery

Processing Type
Standard

Condition
New

Height
90 Millimeter (mm)

Function
Response Time

Application
Industrial Machinery

Product Type
PLC

Weight
200 Grams (g)

Color
White

Power Mode
Other

Width
25.2 Millimeter (mm)

Length
60 Millimeter (mm)

Voltage
24V DC Volt (v)

Warranty
1 Year

DVP04DA-H2 - Delta PLC Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About DVP04DA-H2 - Delta PLC

The

DVP04DA-H2

is a 4-channel analog output expansion module designed for high-end Delta DVP-EH2 and EH3 Series PLCs. It converts 12-bit digital data from the main PLC unit into precision analog voltage or current signals to control external devices like AC motor drives, valves, and recorders.

DVP04DA-H2

Analog Module

4 points of analog voltage (0 V +10 V) / current (0 mA +20 mA) output *1

Resolution: 12-bit

Built-in RS-485 interface

Product category
PLC
sub-category
DVP-Standard Series
Partner name
Delta
Series name
DVP-EH3 Expansion

Attributes

PLC Module
Expansion Module
I/O Selection
Separate AI/AO
Supply
24VDC
Output Type
N.A.

Key Specifications & Functions

Analog Outputs: 4 channels per module, selectable between voltage and current via wiring.
- Voltage Range: 0V to +10V DC (Resolution: 12-bit, 2.5mV per LSB).
- Current Range: 0mA to 20mA (Resolution: 12-bit, 5A per LSB).
Response Time: Rapid conversion at 3ms multiplied by the number of active channels.
Power Supply: Operates on 24V DC (20.4V to 28.8V DC).
Communication: Features a built-in RS-485 interface supporting MODBUS ASCII/RTU protocols for standalone configuration or monitoring.
Protection: Voltage outputs are protected against short circuits.
