DVP04PT-H2 - Delta PLC

Name: DVP04PT-H2 - Delta PLC
Brand: Corbital Enterprise
Price: 24000.0 INR
Availability: InStock

Price 24000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Number

DVP04PT-H2 - Delta PLC Specification

Humidity
5% to 95%

Mounting Type
DIN Rail

Rated Voltage
24V DC Volt (V)

Input Current
24V DC

Phase
DC power

Output Voltage
24V DC Volt (V)

Usage
Industrial Machinery

Processing Type
Standard

Condition
New

Function
Temperature Range:

Height
90 Millimeter (mm)

Application
Industrial Machinery

Product Type
PLC

Weight
450 Grams (g)

Power Mode
Other

Color
White

Length
60 Millimeter (mm)

Voltage
24V DC Volt (v)

Width
25.2 Millimeter (mm)

Warranty
1 Year

DVP04PT-H2 - Delta PLC Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About DVP04PT-H2 - Delta PLC

The

DVP04PT-H2

is a 4-channel platinum resistance thermometer (RTD) temperature measurement module for the Delta DVP-EH2 and EH3 Series PLCs. It converts signals from RTD sensors into 14-bit (or 16-bit depending on model version) digital signals, allowing the PLC to monitor and control industrial temperatures with high precision.

DVP04PT-H2

Analog Module

4 points of platinum RTD (Pt100, Pt1000, Ni100, Ni1000) sensor input *1 / 0 300

0 3000 resistance input

Resolution: 0.1C

Built-in RS-485 interface

Product category
PLC
sub-category
DVP-Standard Series
Partner name
Delta
Series name
DVP-EH3 Expansion

Attributes

PLC Module
Expansion Module
I/O Selection
Separate AI/AO
Supply
24VDC
Output Type
N.A.
In Built
NO

Key Specifications & Functions

Input Channels: 4 channels per module, supporting 3-wire PT100, PT1000, NI100, and NI1000 sensors.
Temperature Range: Measures between -200C to 600C (-328F to 1112F).
Resolution: Displays temperatures in Celsius (0.1C resolution) and Fahrenheit (0.18F resolution).
Power Supply: Operates on 24V DC (20.4V to 28.8V DC) with a consumption of 2.5W.
Communication: Features a built-in RS-485 interface (MODBUS ASCII/RTU) for standalone data access or monitoring.
Protection: Designed as an OPEN-TYPE device, it must be installed in an enclosure free of dust and humidity to ensure reliable operation.
