DVP10EC00T3 - Delta PLC

Power supply voltage

100 ~ 240VAC (-15% ~ 10%), 50/60Hz + -5%

Operation

DVP-EC3 starts to run when the power supply rises to 95 ~ 100V AC and

stops when the power supply drops to 70V AC. It continues to run for 10ms

after the power supply is cut off.

Power supply fuse

2A/250VAC

Power consumption

12VA

15.6VA

22.5VA

DC24V current output

200mA

300mA

400mA

Power supply protection

DC24V output short circuit protection

Voltage withstand

1,500VAC (Primary-secondary), 1,500VAC (Primary-PE), 500VAC

(Secondary-PE)

Insulation resistance

> 5M at 500VDC (between all I/O points and earth)

Noise immunity

ESD (IEC 61131-2, IEC 61000-4-2): 8kV Air Discharge

EFT (IEC 61131-2, IEC 61000-4-4): Power Line: 2kV, Digital I/O: 1kV, Analog

& Communication I/O: 1kV

RS (IEC 61131-2, IEC 61000-4-3): 26MHz ~ 1GHz, 10V/m

Grounding

The diameter of grounding wire shall not be less than that of L, N terminal of

the power supply. (When many PLCs are in use at the same time, please

make sure every PLC is properly grounded.)

Operation/storage

Operation: 0 C ~55 C (temperature), 50~95% (humidity), pollution degree 2

Storage: -25 C ~70 C (temperature), 5~95% (humidity)

Agency approvals

UL508

European community EMC Directive 89/336/EEC and Low Voltage Directive

73/23/EEC

Vibration/shock immunity

International standards: IEC61131-2, IEC 68-2-6 (TEST Fc)/ I
