ECMA-JA1020RS Delta Servo Motor 2000W L , Torque Nm - 6.37 , RPM - 3000

Name: ECMA-JA1020RS Delta Servo Motor 2000W L , Torque Nm - 6.37 , RPM - 3000
Brand: Corbital Enterprise
Price: 47000.0 INR
Availability: InStock

Price 47000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

ECMA-JA1020RS Delta Servo Motor 2000W L , Torque Nm - 6.37 , RPM - 3000 Specification

Sealed Type
Packing seal

Product Type
Servo Motor

Color
Black and Silver

Usage & Applications
Industrial Machinerry

Weight
8.6 Kilograms (kg)

Warranty
1 Year

Phase
Three Phase

Material
Aluminum

ECMA-JA1020RS Delta Servo Motor 2000W L , Torque Nm - 6.37 , RPM - 3000 Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About ECMA-JA1020RS Delta Servo Motor 2000W L , Torque Nm - 6.37 , RPM - 3000

The Delta ECMA-JA1020RS is a high-power 2000W absolute-type servo motor. It functions as the primary precision actuator for 400V industrial machines that require rapid motion without losing position data during power cycles.

Core Functions

Absolute Position Tracking: Unlike incremental motors, the 17-bit absolute encoder (131,072 pulses/rev) acts like a permanent digital map. It knows its exact physical location even if the machine is moved while turned off, eliminating the time-consuming "homing" procedure every morning.
High-Speed Response (Low Inertia): Designed for "start-stop" efficiency. Its low-inertia rotor allows it to accelerate to 3000 RPM almost instantly, which is vital for high-speed packaging, labeling, and pick-and-place robotics.
Precision Under Load: Delivers a constant 6.37 Nm of torque (peaking at 19.11 Nm). This ensures that even when moving heavy mechanical parts, it maintains its target speed and position without "slipping" or lagging.
Advanced Smoothness: When used with an ASDA-A2 drive, it utilizes 1 kHz frequency response and internal filters to suppress mechanical resonance, ensuring that high-power movements don't cause the machine frame to vibrate.

Typical Applications

Automated Tool Changers: Where knowing the exact position of the tool carousel is critical for safety.
High-Speed Packaging: For synchronized motion in "flying shear" or "rotary cut" applications.
Multi-Axis Robotics: Providing high-torque, absolute-precision joints for industrial robot arms.

The physical specifications for the Delta ECMA-JA1020RS (2000W / 2kW model without brake) in inches and pounds are as follows:

Dimensions & Weight

Attribute	Measurement (Inches)	Measurement (Metric)
Total Length	7.56 in	192 mm
Height (Frame)	3.94 in	100 mm
Width (Frame)	3.94 in	100 mm
Shaft Diameter	0.945 in	24 mm
Shaft Length	2.165 in	55 mm
Net Weight	18.96 lbs	8.6 kg

Key Technical Notes

Absolute Encoder: Like the 1000W version, the "JA" series features a 17-bit absolute encoder. This allows the system to retain its position after power-off, removing the need for homing sensors.
Voltage Class: This is a 400V VAC motor, designed for three-phase industrial power systems.
Low Inertia: Despite its high weight, it is a Low Inertia model, allowing for rapid acceleration and decelerationideal for high-speed pick-and-place or packaging tasks.
Brake Status: The "RS" suffix means this unit does not have a brake. If you need this for a vertical axis, you would require the "SS" model.
Protection: It carries an IP65 rating, making it resistant to dust and low-pressure water jets. [1, 2, 3, 4]
