ECMA-JA1020SS Delta Servo Motor 2000W L , Torque Nm - 6.37 , RPM - 3000
ECMA-JA1020SS Delta Servo Motor 2000W L , Torque Nm - 6.37 , RPM - 3000
ECMA-JA1020SS Delta Servo Motor 2000W L , Torque Nm - 6.37 , RPM - 3000
ECMA-JA1020SS Delta Servo Motor 2000W L , Torque Nm - 6.37 , RPM - 3000
ECMA-JA1020SS Delta Servo Motor 2000W L , Torque Nm - 6.37 , RPM - 3000
ECMA-JA1020SS Delta Servo Motor 2000W L , Torque Nm - 6.37 , RPM - 3000
ECMA-JA1020SS Delta Servo Motor 2000W L , Torque Nm - 6.37 , RPM - 3000
ECMA-JA1020SS Delta Servo Motor 2000W L , Torque Nm - 6.37 , RPM - 3000
ECMA-JA1020SS Delta Servo Motor 2000W L , Torque Nm - 6.37 , RPM - 3000
ECMA-JA1020SS Delta Servo Motor 2000W L , Torque Nm - 6.37 , RPM - 3000
ECMA-JA1020SS Delta Servo Motor 2000W L , Torque Nm - 6.37 , RPM - 3000
ECMA-JA1020SS Delta Servo Motor 2000W L , Torque Nm - 6.37 , RPM - 3000

ECMA-JA1020SS Delta Servo Motor 2000W L , Torque Nm - 6.37 , RPM - 3000

Price 62000.0 INR/ Number

MOQ : 1 Number

ECMA-JA1020SS Delta Servo Motor 2000W L , Torque Nm - 6.37 , RPM - 3000 Specification

  • Humidity %
  • 5 To 95
  • IP Rating
  • 65
  • Product Type
  • Servo Motor
  • Application
  • Industrial Machinery
  • Color
  • Black
  • Usage & Applications
  • Industrial Machinery
  • Warranty
  • 1 Year
  • Phase
  • 3 Phase
  • Material
  • 3 Phase


ECMA-JA1020SS Delta Servo Motor 2000W L , Torque Nm - 6.37 , RPM - 3000 Trade Information

  • Minimum Order Quantity
  • 1 Number
  • Delivery Time
  • 24 Hours


About ECMA-JA1020SS Delta Servo Motor 2000W L , Torque Nm - 6.37 , RPM - 3000

The Delta ECMA-JA1020SS is a high-performance 2000W (2 kW) AC servo motor from the ASDA-A2 Series, designed for industrial applications requiring precise positioning and high-speed motion control. [1, 2]
Core Specifications
  • Rated Output Power: 2.0 kW (2000W).
  • Rated Torque: 6.37 Nm (Peak torque up to 19.1 Nm).
  • Rated Speed: 3000 RPM (Maximum mechanical speed up to 5000 RPM).
  • Input Voltage: 400V AC.
  • Encoder Type: 17-bit Absolute encoder.
  • Brake: Included (Integrated electromagnetic brake for precise holding).
  • Frame Size: 100 mm flange.
  • Shaft Diameter: 22 mm with keyway and oil seal.

Key Features
  • Precision Control: Equipped with a high-resolution absolute encoder, it ensures stable rotation even at low speeds and high-precision positioning.
  • Vibration Suppression: Features built-in automatic low-frequency vibration suppression filters to minimize movement at machine edges.
  • Rugged Design: Typically rated at IP65 for protection against dust and water, making it suitable for harsh industrial environments like CNC machinery and robotic arms. [1, 2, 3, 4]


The Delta ECMA-JA1020SS servo motor has the following physical dimensions and weight converted to imperial units: [1, 2]
Dimensions & Weight
  • Weight: 19.62 lbs (8.9 kg).
  • Length: 8.90 inches (226 mm).
  • Width (Frame Size): 3.94 inches (100 mm).
  • Height (Frame Size): 3.94 inches (100 mm). [1, 2, 4, 5]
Shaft Specifications
  • Shaft Diameter: 0.87 inches (22 mm).
  • Shaft Length: 1.77 inches (45 mm). [1, 2, 3]
