GD200A-018G/022P-4 INVT VFD 18.5 kW / 25HP 415V

Name: GD200A-018G/022P-4 INVT VFD 18.5 kW / 25HP 415V
Brand: Corbital Enterprise
Price: 28500.0 INR
Availability: InStock

Price 28500.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

GD200A-018G/022P-4 INVT VFD 18.5 kW / 25HP 415V Specification

Feature
Performance

Humidity %
5% to 95%

Mounting Type
DIN-rail mounting

IP Rating
20

Power Rating
220V (-15%) to 240V (+10%)

Product Type
VFD

Application
Industrial Machinery

Color
Black

Usage & Applications
Industrial Machinery

Weight
6.5 Kilograms (kg)

Rated Voltage
220V (-15%) to 240V (+10%) Volt (V)

Warranty
1 Year

Phase
3 Phase

Input Voltage
220V (-15%) to 240V (+10%) Volt (V)

Rated Current
220V (-15%) to 240V (+10%) Volt (v)

Material
Plastic

Features
Safety & EMC

GD200A-018G/022P-4 INVT VFD 18.5 kW / 25HP 415V Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About GD200A-018G/022P-4 INVT VFD 18.5 kW / 25HP 415V

The INVT GD200A-018G/022P-4 is a high-capacity Variable Frequency Drive with a dual-power rating for 18.5 kW (25 HP) and 22 kW (30 HP) applications. It is part of the GD200A general-purpose series, known for its high environmental adaptability and precise vector control.

Dual Power Ratings

G (Heavy Duty / Constant Torque): 18.5 kW / 25 HP with a rated output current of 38 Amps.
P (Normal Duty / Variable Torque): 22 kW / 30 HP with a rated output current of 45 Amps.

Manufacturer:	INVT
Series:	GD 200A
Model:	GD200A-018G/022P-4
Application:	general purpose
Capacity, kW:	18,5/22
Current, :	38/45
Main power supply, V:	400
Phase:	3
Output frequency, Hz:	0-400
Enclosure:	IP20
Overload capacity, % per 1 min.:	150
EMC filter:	Built-in C3 filter
Braking unit:	external barking
Analog input:	2
Digital input:	9
Analog output:	2
Digital output:	2

Physical Dimensions & Weight

This model uses the Frame 6 enclosure, which provides more room for internal heat dissipation compared to the Frame 5 units.

Height: 12.60 inches (320 mm)
Width: 6.69 inches (170 mm)
Depth: 7.73 inches (196.3 mm)
Net Weight: Approximately 14.33 lbs (6.5 kg).

Key Features

Performance: Uses Sensorless Vector Control (SVC) to achieve 150% torque at 0.5 Hz, essential for heavy industrial loads.
Industrial Hardening: Features an independent air duct design and thickened conformal coating to protect against dust and moisture.
Safety & EMC: Includes a built-in C3 EMC filter and an integrated braking unit (chopper) for controlled stopping of high-inertia loads.
Connectivity: Supports Modbus RTU communication via RS485 and includes multiple I/O channels (8 Digital Inputs, 2 Analog Inputs).
