GD200A-030G/037P-4 INVT VFD 30 kW / 40HP 415V

Price 41400.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

GD200A-030G/037P-4 INVT VFD 30 kW / 40HP 415V Specification

Humidity %
5% to 95%

IP Rating
20

Feature
Sensorless Vector Control (SVC)

Mounting Type
DIN-rail mounting

Power Rating
220V (-15%) to 240V (+10%)

Product Type
VFD

Application
Industrial Machinery

Color
Black

Rated Voltage
220V (-15%) to 240V (+10%) Volt (V)

Usage & Applications
Industrial Machinery

Weight
10.5 Kilograms (kg)

Warranty
1 Year

Phase
3 Phase

Input Voltage
220V (-15%) to 240V (+10%) Volt (V)

Material
Plastic

Rated Current
220V (-15%) to 240V (+10%) Volt (v)

Features
Industrial Design

GD200A-030G/037P-4 INVT VFD 30 kW / 40HP 415V Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About GD200A-030G/037P-4 INVT VFD 30 kW / 40HP 415V

The

INVT GD200A-030G/037P-4

is a high-performance, 30 kW (40 HP) / 37 kW (50 HP) general-purpose Variable Frequency Drive. It features a dual-power rating to handle different industrial load types efficiently:

G (General/Heavy Duty): 30 kW / 40 HP for constant torque loads (e.g., air compressors) with a 60 A output current.

P (Pump/Normal Duty): 37 kW / 50 HP for variable torque loads (e.g., fans and pumps) with a 75 A output current.

Manufacturer:	INVT
Series:	GD 200A
Model:	GD200A-030G/037P-4
Application:	general purpose
Capacity, kW:	30/37
Current, :	60/75
Main power supply, V:	400
Phase:	3
Output frequency, Hz:	0-400
Enclosure:	IP20
Overload capacity, % per 1 min.:	150

Physical Specifications

Dimensions (W x H x D): Approximately 9.84 x 15.75 x 7.95 inches (250 x 400 x 202 mm).

Net Weight: Approximately 23.15 lbs (10.5 kg)

Key Features

Performance: Utilizes advanced Sensorless Vector Control (SVC) and V/f control for accurate motor autotuning and high starting torque (150% at 0.5 Hz).

Industrial Design: Features an independent air duct design and enhanced protection against dust, humidity, and temperature grid fluctuations (-10C to +50C).

Hardware: Includes a standard built-in C3 EMC filter, an integrated braking unit (standard for $\leq$30 kW models), and support for an external LED keypad to copy parameters.
