GD200A-0R7G-4 INVT VFD 0.75 kW / 1HP 415V

Name: GD200A-0R7G-4 INVT VFD 0.75 kW / 1HP 415V
Brand: Corbital Enterprise
Price: 7800.0 INR
Availability: InStock

Price 7800.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

GD200A-0R7G-4 INVT VFD 0.75 kW / 1HP 415V Specification

Feature
Advanced Vector Control

Mounting Type
DIN-rail mounting

IP Rating
20

Humidity %
5% to 95%

Product Type
VFD

Power Rating
220V (-15%) to 240V (+10%)

Application
Industrial Machinery

Protection Level
Other

Color
Black

Rated Voltage
220V (-15%) to 240V (+10%) Volt (V)

Usage & Applications
Industrial Machinery

Warranty
1 Year

Input Voltage
220V (-15%) to 240V (+10%) Volt (V)

Phase
3 Phase

Rated Current
220V (-15%) to 240V (+10%) Volt (v)

Material
Plastic

Features
Robust Hardware

GD200A-0R7G-4 INVT VFD 0.75 kW / 1HP 415V Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About GD200A-0R7G-4 INVT VFD 0.75 kW / 1HP 415V

The

INVT GD200A-0R7G-4

is a 0.75 kW (1 HP) heavy-duty general-purpose Variable Frequency Drive from the Goodrive200A series. Unlike the compact GD20 series you previously asked about, the GD200A is a full-sized vector control drive designed for broader industrial stability and enhanced environment adaptability

Brand	Others
Voltage	220V
Phase	3 Phase
Input Voltage	380V-440v
Input Frequency	50Hz-60Hz
Brand	Powermag
Phases	Three phase

Physical Specifications

The chassis for this 1 HP model is larger than the equivalent GD20 unit to allow for better heat dissipation and hardware expansion.

Height: 10.83 inches (275 mm)
Width: 8.07 inches (205 mm)
Depth: 9.25 inches (235 mm)
Net Weight: Approximately 2.5 kg (5.51 lbs)

Key Features

Advanced Vector Control: Utilizes high-performance speed sensorless vector control and V/F control modes for precise motor speed and torque regulation.
High Starting Torque: Provides up to 150% torque at 0.5 Hz, making it suitable for demanding startup applications like air compressors and heavy conveyors.
Dual Power Rating: Supports G/P (General/Pump) dual ratings, allowing it to be used for both heavy-duty and normal-duty loads.
Robust Hardware: Features a standard built-in C3 filter and a standard membrane keypad, with an optional external LED or LCD keypad for remote control and parameter copying.
Reliability: Includes an independent air duct design and advanced protection for overvoltage, overcurrent, and motor autotuning.

Hardware & Safety

C3 Filter Integration: Comes with a built-in C3 EMC filter to reduce electromagnetic interference with other electronics.
Safe Torque Off (STO): Provides a high-level safety function to prevent accidental motor startups during maintenance.
Reliable Cooling: Equipped with a high-efficiency pluggable cooling fan designed for easy cleaning and replacement in dusty environments.
Modbus Communication: Includes an RS485 port for remote monitoring of pump status and performance data via PLC or IoT devices.
