GD200A-200G/220P-4 INVT VFD 200 kW / 270HP 415V

Name: GD200A-200G/220P-4 INVT VFD 200 kW / 270HP 415V
Brand: Corbital Enterprise
Price: 211000.0 INR
Availability: InStock

Price 211000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

GD200A-200G/220P-4 INVT VFD 200 kW / 270HP 415V Specification

IP Rating
20

Humidity %
5% to 95%

Mounting Type
DIN-rail mounting

Feature
EMC Safety

Product Type
VFD

Power Rating
220V (-15%) to 240V (+10%)

Application
Industrial Machinery

Color
Black

Rated Voltage
220V (-15%) to 240V (+10%) Volt (V)

Weight
152 Kilograms (kg)

Usage & Applications
Industrial Machinery

Warranty
1 Year

Input Voltage
220V (-15%) to 240V (+10%) Volt (V)

Phase
3 Phase

Material
Plastic

Rated Current
220V (-15%) to 240V (+10%) Volt (v)

Features
Communication

GD200A-200G/220P-4 INVT VFD 200 kW / 270HP 415V Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About GD200A-200G/220P-4 INVT VFD 200 kW / 270HP 415V

The INVT GD200A-200G/220P-4 is a high-power industrial Variable Frequency Drive (VFD) featuring a dual-power rating. It is designed for massive industrial loads such as large-scale air compressors, mining extruders, and municipal water station pumps.

Dual Power Ratings

G (General/Heavy Duty): 200 kW / 270 HP for constant torque loads with a 380 A output current.

P (Pump/Normal Duty): 220 kW / 300 HP for variable torque loads (fans/pumps) with a 430 A output current.

Physical Specifications (Inches)

This unit uses the Frame 10 industrial enclosure, which is a floor-standing cabinet designed to handle the high heat and weight of a 270+ HP system.

Height: 48.62 inches (1235 mm)
Width: 19.69 inches (500 mm)
Depth: 14.17 inches (360 mm)
Net Weight: Approximately 335 lbs (152 kg).

Key Performance Features

Control Logic: High-speed DSP-based Sensorless Vector Control (SVC) delivering 150% torque at 0.5 Hz for heavy-load startups.

EMC Safety: Integrated C3 filter as standard to minimize electromagnetic interference in large plant environments.

Industrial Hardening: Features an independent air duct design and thickened conformal coating on circuit boards to resist dust and humidity.

Communication: Standard RS485 port supporting Modbus RTU/ASCII for seamless SCADA or PLC integration.

High-Performance Industrial VFD

Designed for heavy-duty applications, the GD200A-200G/220P-4 INVT VFD guarantees efficient motor control in industries requiring consistent performance. Its 200 kW capacity and adaptability to fluctuating voltages make it perfect for various industrial setups. With reliable protection features, it minimizes downtime and increases operational longevity, supporting high-volume industrial demands.

Simple Installation and Versatile Use

With DIN-rail mounting, setting up the VFD is fast and efficient. Its robust construction and IP20 rating ensure safety in diverse industrial environments. The unit fits seamlessly into existing systems, making it a preferred choice for suppliers, traders, and wholesalers across India.

FAQ's of GD200A-200G/220P-4 INVT VFD 200 kW / 270HP 415V:

Q: How can I install the GD200A-200G/220P-4 INVT VFD in my industrial machinery setup?

A: The VFD is designed for an easy DIN-rail mounting, enabling quick integration into industrial machinery panels. Follow the installation manual to ensure secure electrical connections and optimal placement for cooling and safety.

Q: What voltage and current ranges are supported by this VFD?

A: This VFD operates with a rated input voltage and current of 220V (-15%) to 240V (+10%) in a 3-phase configuration, supporting machinery that requires stable power within these parameters.

Q: When should the GD200A-200G/220P-4 be used in industrial applications?

A: This VFD is ideal when precise speed control, energy savings, and secure motor operation are necessary for industrial machinery, particularly where power ratings up to 200 kW are required.

Q: Where is this variable frequency drive typically used?

A: It is commonly installed in industrial facilities throughout India, especially in sectors utilizing heavy machinery, such as manufacturing plants and process industries that need reliable, efficient motor control.

Q: What beneficial features does this VFD offer for industrial usage?

A: Key features include EMC safety, advanced communication protocols, and IP20 protection. These contribute to safe operation, system integration, and reducing electrical interference in sensitive environments.

Q: How does the VFD ensure safe and reliable operation under varying humidity conditions?

A: The unit operates efficiently in humidity levels from 5% to 95%, aided by its robust plastic housing and internal safety features, minimizing the risk of condensation damage or malfunction.

Q: What is the warranty period for the GD200A-200G/220P-4 INVT VFD and what does it cover?

A: This product comes with a 1-year warranty, covering defects in material or workmanship under normal operating conditions, ensuring peace of mind for industrial users.
