MADLN05SE - A6SE Panasonic A6 100W Driver

Name: MADLN05SE - A6SE Panasonic A6 100W Driver
Brand: Corbital Enterprise
Price: 35000.0 INR
Availability: InStock

Price 35000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

MADLN05SE - A6SE Panasonic A6 100W Driver Specification

Product Type
VFD

Application
Industrial Machinerry

Color
Black and Silver

Usage & Applications
Industrial Machinerry

Weight
0.8 Kilograms (kg)

Warranty
1 Year

Phase
Three Phase

Material
Aluminum

MADLN05SE - A6SE Panasonic A6 100W Driver Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
24 Hours

About MADLN05SE - A6SE Panasonic A6 100W Driver

Key Specifications

Series: MINAS A6 (A6SE type)
Rated Power: 100 W
Control Type: Position control only (pulse train)
System: Incremental encoder only (no absolute system)
Safety Function: Not available
Communication: USB only (for setup/monitoring)
Supply Voltage: 200240V AC (single/3-phase)
Key Specifications
- Series: MINAS A6 (A6SE type)
- Rated Power: 100 W
- Control Type: Position control only (pulse train)
- System: Incremental encoder only (no absolute system)
- Safety Function: Not available
- Communication: USB only (for setup/monitoring)
- Supply Voltage: 200240V AC (single/3-phase)
Dimensions
- Width: 40 mm 1.57 inch
- Height: 150 mm 5.91 inch
- Depth: 130 mm 5.12 inch
Weight
- 0.8 kg (1.76 lbs)
Features
- 3.2 kHz high-speed response (fast positioning)
- Pulse input control (line driver / open collector)
- 10 inputs / 6 outputs configurable I/O
- Supports internal positioning (up to 256 positions)
- External regenerative resistor required (no built-in)
- Core Functions

  1. Position Control (Primary Function)
  - Works on pulse train input (PUL/DIR signals)
  - Converts pulses into precise motor movement
  - Used for:
    - Exact positioning
    - Indexing
    - Step-like motion
  This is its main and only major control function

  2. Incremental Encoder Feedback
  - Uses encoder feedback to:
    - Check actual position
    - Correct errors in motion
  - Works in incremental mode only (no absolute positioning)
  3. High-Speed Response
  - 3.2 kHz response
  - Ensures:
    - Fast reaction
    - Smooth and accurate movement
  Good for high-speed machines

  4. PLC Interface Control
  - Takes commands from:
    - PLC (like Siemens, Delta, Mitsubishi)
  - Input types:
    - Pulse + Direction
    - Line driver / open collector
  5. Internal Positioning (Optional)
  - Can store up to 256 positions internally
  - Useful when:
    - You dont want full PLC programming
    - Simple repetitive motion is needed
  6. Monitoring & Setup
  - USB connection for:
    - Parameter setting
    - Monitoring (via Panasonic software)

Exceptional Efficiency for Industrial Machinery

The MADLN05SE - A6SE Panasonic A6 100W Driver is designed for integration in various types of industrial machinery, supporting optimal operation across heavy-duty applications. Its three-phase capability ensures stability and energy efficiency, making it indispensable for manufacturing and automation processes.

Durable, Lightweight Construction

Constructed with premium aluminum and sporting a black and silver finish, this driver provides durability without excess weight. Its 0.8 kg build makes installation and maintenance straightforward, reducing downtime in demanding industrial settings.

FAQ's of MADLN05SE - A6SE Panasonic A6 100W Driver:

Q: How is the MADLN05SE - A6SE Panasonic A6 100W Driver installed in industrial machinery?

A: The driver is designed for seamless integration into industrial machinery. It should be mounted in accordance with the manufacturer's guidelines, ensuring secure connection to the three-phase power supply and proper alignment with the motor or control system.

Q: What are the main benefits of using this 100W driver in an industrial setting?

A: Key benefits include high reliability, excellent energy efficiency, and strong performance in demanding environments. Its lightweight aluminum construction also makes it easy to handle during installation and maintenance.

Q: When should I consider replacing the driver?

A: It is recommended to monitor the driver for any signs of performance decline, overheating, or unusual noise. Replacement should be considered if these issues arise or after extensive use, even though the included 1-year warranty offers assurance during its initial operational period.

Q: Where can the MADLN05SE - A6SE Panasonic A6 100W Driver be used?

A: This driver is suitable for various industrial applications, particularly in environments where high efficiency and durable components are essential, such as manufacturing plants or automated production lines.

Q: What materials are used in the construction of the driver?

A: The device is constructed primarily from aluminum, offering a combination of strength, corrosion resistance, and lightweight properties, finished in a professional black and silver color scheme.

Q: How can using this driver improve my machinery's process?

A: By integrating this Panasonic driver, the machinery benefits from stable power delivery, improved operational accuracy, and reduced energy consumption, ensuring smoother and more reliable processes.
