SE3-021-1.5K Shihlin AC Drive 220V

Price 17500.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

SE3-021-1.5K Shihlin AC Drive 220V Specification

Product Type
VFD

Application
Industrial Machinerry

Color
Charcoal Black

Weight
1.7 Kilograms (kg)

Usage & Applications
Industrial Machinerry

Warranty
1 Year

Phase
3 Phase

Material
Polycarbonate

SE3-021-1.5K Shihlin AC Drive 220V Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About SE3-021-1.5K Shihlin AC Drive 220V

The Shihlin SE3-021-1.5K AC Drive is a high-performance general-purpose inverter designed for 1.5 kW (2 HP) 3-phase asynchronous or permanent magnet (PM) motors. It operates on a 220V AC single-phase power supply, making it a powerful solution for precision motor control in industrial settings.

Core Functions & Features

Dual Motor Support: Controls both Induction Motors (IM) and Synchronous Motors (IPM/SPM).
Advanced Control Modes: Supports V/F, Sensorless Vector, and Closed-loop Vector control for high-accuracy steady speeds (error < 0.02%).
Expansion Capability: Includes one expansion card slot for optional Closed-loop feedback, additional communication (Profibus, EtherCAT), or relay cards.
Built-in PLC: Features simple PLC functionality for basic logic without needing external controllers.
Braking & Safety: Equipped with a built-in braking unit for rapid deceleration and protection against overcurrent, short circuits, and overheating.
Communication: Standard MODBUS protocol over RS-485. [1, 2, 3]

Physical Specifications (Frame B)

This model typically belongs to Frame B, which is slightly larger than the entry-level models to manage its higher current and heat dissipation requirements. [1]

Specification [1, 2, 3]	Metric Measurement	Imperial Measurement (Approx.)
Weight	1.7 kg to 2.1 kg*	~3.75 lbs to 4.63 lbs*
Height (H)	178 mm	~7.01 inches
Width (W)	105 mm	~4.13 inches
Depth (D)	146 mm	~5.75 inches
*Note: Net weight is ~1.7 kg; shipping weight is approximately 2.1 kg.
