SE3-043-1.5K Shihlin AC Drive 440V

Price 16400.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

SE3-043-1.5K Shihlin AC Drive 440V Specification

Product Type
VFD

Application
Industrial Machinerry

Color
Charcoal Black

Weight
1 Kilograms (kg)

Usage & Applications
Industrial Machinerryx

Warranty
1 Year

Phase
3 Phase

Material
Polycarbonate

SE3-043-1.5K Shihlin AC Drive 440V Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About SE3-043-1.5K Shihlin AC Drive 440V

The Shihlin SE3-043-1.5K is a 440V class, high-performance AC drive with a power rating of 1.5 kW (2 HP). It is part of the Frame A design within the SE3 series, known for its compact footprint and support for both induction (IM) and permanent magnet (PM) motors.

Dimensions and Weight

This model maintains the same compact Frame A footprint as the 0.75kW version, allowing for high power density in small control panels. [1]

Dimension [1, 2]	Metric (mm/kg)	Imperial (inches/lbs)
Height (H)	167.0 mm	6.57 inches
Width (W)	74.0 mm	2.91 inches
Length/Depth (D)	144.0 mm	5.67 inches
Weight	1.0 kg	2.20 lbs

Core Specifications

Rated Power: 1.5 kW (2 HP).
Input Voltage: 3-Phase 380480V (Permissible: 323528V).
Rated Output Current:
- Heavy Duty (HD): 4.2A (150% overload for 60s).
- Normal Duty (ND): 4.6A (120% overload for 60s).
Output Frequency: 0599 Hz (High-speed version supports up to 1500 Hz).
Cooling Method: Self-cooling (no fan required for this frame size), which reduces maintenance and noise.
Communication: Dual RS-485 interfaces supporting MODBUS RTU and Shihlin protocols. [, 2, 3, 4, 5]

Features and Protection

Control Modes: V/F, General Flux Vector, and Sensorless Vector Control (SVC) for precise torque at low speeds.
Safety: Built-in protections for output short circuit, overcurrent, overvoltage, motor overheating, and ground leakage.
Interference: Includes an integrated RFI filter to comply with CE regulations and minimize noise for nearby electronics. [1, 2, 3, 4]
