SE3-043-18.5K Shihlin AC Drive 440V

Name: SE3-043-18.5K Shihlin AC Drive 440V
Brand: Corbital Enterprise
Price: 37100.0 INR
Availability: InStock

Price 37100.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

SE3-043-18.5K Shihlin AC Drive 440V Specification

Product Type
VFD

Application
Industrial Machinerry

Color
Charcoal Black

Weight
5.8 Kilograms (kg)

Usage & Applications
Industrial Machinerry

Warranty
1 Year

Phase
3 Phase

Material
Polycarbonate

SE3-043-18.5K Shihlin AC Drive 440V Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About SE3-043-18.5K Shihlin AC Drive 440V

The Shihlin SE3-043-18.5K is a 440V class, high-performance AC drive with a power rating of 18.5 kW (25 HP). It is housed in the Frame D enclosure, making it a robust solution for heavy industrial applications requiring precise motor speed and torque control.

Key Specifications

Rated Power: 18.5 kW (25 HP).
Input Voltage: 3-Phase 380480V AC (50/60 Hz).
Rated Output Current:
- Normal Duty (ND): 38.0A IndiaMART.
Control Modes: Supports V/F control and Sensorless Vector Control (SVC) for high-accuracy speed regulation Shihlin Electric.
Overload Endurance: Capable of 150% for 60 seconds and 200% for 3 seconds (Heavy Duty mode) Scribd User Manual.
Cooling Method: Forced Air Cooling via an integrated internal fan. [1, 2, 3, 4]

Dimension [1, 2, 3]	Metric (mm/kg)	Imperial (inches/lbs)
Height (H)	300.0 mm	11.81 inches
Width (W)	175.0 mm	6.89 inches
Length/Depth (D)	192.0 mm	7.56 inches
Weight	5.8 kg	12.79 lbs

Features and Benefits

Dual Motor Support: Compatible with both standard Induction Motors (IM) and Permanent Magnet Motors (PM).
High-Speed Output: Can reach a maximum output frequency of 1500 Hz for specialized high-speed machinery.
Built-in PLC: Includes localized logic control, reducing the need for external control hardware in simple automation tasks.
Communication: Integrated RS-485 port supporting MODBUS RTU; expandable with cards for EtherCAT, Profibus, and CANopen.
