SS2-021-1.5K Shihlin AC Drive 220V

Name: SS2-021-1.5K Shihlin AC Drive 220V
Brand: Corbital Enterprise
Price: 8900.0 INR
Availability: InStock

Price 8900.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

SS2-021-1.5K Shihlin AC Drive 220V Specification

IP Rating
20

Humidity %
90

Product Type
VFD

Application
Industrial Machinerry

Color
Charcoal Black

Weight
1.6 Kilograms (kg)

Usage & Applications
Industrial Machinerry

Warranty
1 Year

Phase
1 Phase

Material
Polycarbonate

SS2-021-1.5K Shihlin AC Drive 220V Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About SS2-021-1.5K Shihlin AC Drive 220V

The SS2-021-1.5K is a 1.5 kW (2 HP) variable frequency drive (VFD) from Shihlin Electric's SS2 Series. It is designed to take a single-phase 220V input and control a three-phase induction motor, making it a popular choice for high-torque industrial applications like conveyors, pumps, and textile machinery. [1, 2]

Physical Dimensions & Weight

Width: 3.15 inches (80 mm).
Height: 6.85 inches (174 mm).
Depth (Length): 5.28 inches (134 mm).
Weight: Approximately 3.53 lbs (1.6 kg). [1, 2]

Key Specifications

Rated Power: 1.5 kW (2 HP).
Input Voltage: Single-phase 200V240V AC, 50/60 Hz.
Output Current: Rated at 8.0 Amps.
Overload Capacity: 150% for 60 seconds; 200% for 0.5 seconds.
Cooling Method: Forced air cooling with a built-in fan to handle the higher heat generation of the 1.5 kW model. [1, 2, 3, 4]

Core Functions

Precision Control: Features advanced flux vector control and V/F control, allowing for a high starting torque of 150% at 3Hz.
Energy Saving: Includes an automatic output voltage control function that reduces power losses during operation.
User Interface: Built-in shuttle knob for easy frequency adjustment and parameter setting.
Automation Ready: Integrated PID control and RS-485 (MODBUS) communication for seamless connection to PLCs. [1, 2, 3, 5, 6]
