VSR48-045 - Crompton VFD - 22kW / 30HP 3-Phase 380V Solar

Name: VSR48-045 - Crompton VFD - 22kW / 30HP 3-Phase 380V Solar
Brand: Corbital Enterprise
Price: 32000.0 INR
Availability: InStock

Price 32000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

VSR48-045 - Crompton VFD - 22kW / 30HP 3-Phase 380V Solar Specification

Product Type
VFD

Application
Industrial Machinerry

Color
Gray or Black

Usage & Applications
Industrial Machinerry

Weight
7.2 Kilograms (kg)

Warranty
1 Year

Phase
3 Phase

Material
Polycarbonate

VSR48-045 - Crompton VFD - 22kW / 30HP 3-Phase 380V Solar Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About VSR48-045 - Crompton VFD - 22kW / 30HP 3-Phase 380V Solar

The Crompton Greaves Emotron VSR48-045 is a heavy-duty 30 HP (22 kW) three-phase solar Variable Frequency Drive (VFD). It is widely deployed to power high-capacity multi-stage agricultural submersible pumps, massive community water infrastructure, and industrial motor loads like industrial flour mills (Atta Chakki) and oil expellers. To dissipate the substantial heat generated by managing a 45-Amp output, this drive utilizes an enlarged, robust frame configuration. [1, 2, 3, 4, 5]

Physical Dimensions (Inches & Pounds)

The exact enclosure layout and weight parameters converted into imperial units are:

Weight: 15.87 lbs (7.2 kg)
Height: 10.08 inches (256 mm)
Width: 7.32 inches (186 mm)
Depth (Thickness): 7.68 inches (195 mm) [, 2, 3, 4]

Technical & Solar Array Specifications

To successfully run a 30 HP motor at full frequency without tripping, your photovoltaic engineering needs to meet the following parameters:

Feature [1, 2, 4, 5]	Specification
Model Number	VSR48-045-20CNB / 20CEB
Power Rating	22.0 kW / 30 HP
Rated Output Current	45.0 Amps
Maximum Input DC Current	63.4 to 70.0 Amps
Recommended Solar Array Power	30.0 to 33.0 kWp
Recommended Voc Range	600V to 700V DC
Optimal MPPT Voltage Range	450V to 600V DC
Maximum Input DC Voltage	800V DC (1000V DC surge tolerance)
