ASD-A2-1021-U* Delta A2 Series Driver - 1000W

Price 34500.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

ASD-A2-1021-U* Delta A2 Series Driver - 1000W Specification

Sealed Type
Packing seal

Product Type
Servo Motor

Usage & Applications
Industrial Machinerry

Color
Black and Silver

Weight
2 Kilograms (kg)

Warranty
1 Year

Phase
Three Phase

Material
Aluminum

ASD-A2-1021-U* Delta A2 Series Driver - 1000W Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About ASD-A2-1021-U* Delta A2 Series Driver - 1000W

The ASD-A2-1021-U is the high-performance 1000W (1.0 kW) AC servo drive from Deltas ASDA-A2 series. It is specifically designed to provide high-resolution control for motors like the ECMA-E11310RS.

Core Power & Electrical

Rated Power: 1000 Watts (1.0 kW).
Input Phase/Voltage: Single-phase or 3-phase, 200V ~ 230V AC (+10% / -15%), 50/60 Hz.
Continuous Output Current: 7.3 Arms.
Frequency Response: 1 kHz (for rapid command execution).
Speed Control Range: 1:5000.

Control & Motion Intelligence

Control Modes: Position, Speed, and Torque.
Feedback Resolution: Supports 20-bit incremental encoders (1,280,000 pulses/rev) and 17-bit absolute encoders.
Electronic Cam (E-CAM): Built-in logic with up to 720 points for master-slave synchronization.
Specialized "U" Features: Includes digital command support, high-speed position capture/compare, and an extension port for digital inputs.

Suppression & Safety

Vibration Suppression: Dual low-frequency vibration filters to prevent mechanical shaking during movement.
Resonance Suppression: Features high-frequency auto-notch filters to eliminate mechanical "humming."
Safety Function: Built-in Safe Torque Off (STO), ensuring hardware-level power cut-off for operator safety.

Connectivity & I/O

Communication: RS-232 and RS-485 interfaces; includes a Mini-USB port for PC configuration via ASDA-Soft.
Digital I/O: 8 programmable inputs and 5 programmable outputs.
Full-Closed Loop: Supports external linear scale feedback to eliminate mechanical backlash in high-precision setups.

Physical Specifications

Width: 2.28 inches (58 mm).
Height: 6.81 inches (173 mm).
Depth: 7.40 inches (188 mm).
Net Weight: ~4.41 lbs (2.0 kg).

For the ASD-A2-1021-U Delta A2 Series Servo Drive (1000W) paired with your medium-inertia motor, here are the details in inches:

Dimensions & Weight

This 1.0 kW drive uses a slightly deeper frame than the lower-wattage models to accommodate larger internal power components.

Dimension	Inches	Millimeters
Width	2.28"	58 mm
Height	6.81"	173 mm
Depth	7.40"	188 mm
Net Weight	~4.41 lbs	2.0 kg

Note: The shipping weight is typically around 8.8 lbs (4.0 kg) with packaging.

Function

The ASD-A2-1021-U acts as the high-speed controller for the 1.0 kW motor, specializing in:

Torque Management: It provides the high current necessary to reach the motor's 4.77 Nm rated torque, ensuring stable performance even under heavy loads.
Advanced Networking: The "U" suffix denotes high-speed digital communication capabilities (RS-485/Modbus) and an extension port for additional I/O.
Electronic Cam (E-CAM): Features built-in E-CAM functions for complex master-slave synchronization without an external controller.
Resonance Suppression: Includes advanced Vibration Suppression algorithms specifically useful for medium-inertia setups to eliminate mechanical "humming" or shaking.
