ASD-B2-2023-B Delta B2 Series Driver - 2000W

Price 40000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

ASD-B2-2023-B Delta B2 Series Driver - 2000W Specification

Sealed Type
Packing seal

Product Type
Servo Motor

Usage & Applications
Industrial Machinerry

Color
Black and Silver

Weight
4 Kilograms (kg)

Warranty
1 Year

Phase
Three Phase

Material
Aluminum

ASD-B2-2023-B Delta B2 Series Driver - 2000W Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About ASD-B2-2023-B Delta B2 Series Driver - 2000W

The ASD-B2-2023-B is a high-capacity 2000W (2.0 kW) AC servo drive in Delta's standard ASDA-B2 Series. It is a step up from the 1.5kW model, providing the extra power and current stability required for larger industrial machinery. [1, 2, 3]

Physical Dimensions (Inches)

Based on technical data from VP Industrial Electronics and TradeIndia:

Width: ~3.54" (90 mm)
Height: ~5.91" (150 mm)
Depth: ~5.91" (150 mm)
Weight: Approximately 8.82 lbs (4.0 kg). [1, 2]

Key Specifications

Rated Power Output: 2000 Watts (2.0 kW).
Input Power: Primarily three-phase 200V230V AC; some variants may support single-phase at reduced efficiency.
Output Current: Rated at 13.4 Arms continuous, with an instant peak of 40.2 Arms Delta AC Drives.
Feedback: Supports 17-bit (160,000 p/rev) and 20-bit high-resolution encoders for ultra-precise motion Automation Ponno.
Protection: Rated IP20 for indoor cabinet use.

Primary Functions

High-Torque Management: Specifically tuned for 2kW motors (like the ECMA-E21320RS) used in heavy-duty lathes, milling machines, and 3D printing systems Haina Automation.
Advanced Control: Features built-in Position, Speed, and Torque modes with Electronic Gearing to match mechanical ratios without changing PLC code.
Resonance Suppression: Includes automatic notch filters that suppress high-frequency vibration during high-speed operation.
Communication: RS-232 and RS-485 ports using MODBUS for easy digital setup and monitoring via ASDA-Soft software. [1, 2, 3, 4, 5]
