ASD-E3-1021-L Delta B2 Series Driver - 1000W

Name: ASD-E3-1021-L Delta B2 Series Driver - 1000W
Brand: Corbital Enterprise
Price: 34100.0 INR
Availability: InStock

Price 34100.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

ASD-E3-1021-L Delta B2 Series Driver - 1000W Specification

Sealed Type
Packing seal

Product Type
Servo Motor

Color
Black and Silver

Usage & Applications
Industrial Machinerry

Weight
1.2 Kilograms (kg)

Phase
Three Phase

Warranty
1 Year

Material
Aluminum

ASD-E3-1021-L Delta B2 Series Driver - 1000W Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About ASD-E3-1021-L Delta B2 Series Driver - 1000W

The Delta ASD-E3-1021-L is a high-performance 1kW (1000W) servo drive from the ASDA-E3 series, designed for precision motion control in industrial automation. [1, 2]

Core Specifications

Rated Power Output: 1000 W (1.0 kW)
Input Voltage: Single-phase or Three-phase 200230 VAC
Continuous Output Current: 7.3 Arms
Maximum Instantaneous Current: 21.21 Arms
Response Bandwidth: 2.5 kHz
Resolution Support: 24-bit (16,777,216 pulses/rev) [1, 2, 3, 4, 5]

The ASD-E3-1021-L is a 1000W (1kW) high-performance servo drive from Deltas advanced ASDA-E3 series. While you mentioned the B2 series, this is actually the modern, high-speed successor designed to drive 1kW motors like your ECM-E3M-E21310SSE.

Function

The drive acts as the "brain" and "power station" for your 1kW motor:

Precision Driving: It converts command signals from your PLC into high-power electrical current to move the 1kW motor with a 2.5 kHz response bandwidth (2.5x faster than the older B2 series).
Closed-Loop Feedback: It continuously reads the 24-bit encoder data from the motor to ensure the machine never "loses steps," even under heavy loads.
Vibration Suppression: It automatically scans and filters out mechanical resonances up to 5000 Hz, which is essential for large machines that tend to "shake" at high speeds.
Command Modes (-L Model): Supports Pulse/Direction (positioning), Analog Input (speed/torque), and RS-485 Modbus (control/monitoring).

Physical Dimensions & Weight (Inches)

The E3 series is designed to be "book-style" (slim) to save space in your electrical panel.

Dimension	Metric (mm)	Imperial (Inches)
Width	60 mm	2.36 in
Height	162 mm	6.38 in
Depth	185 mm	7.28 in
Weight	1.6 kg	3.53 lbs

Specifications

Rated Power: 1000 W (1.0 kW)
Input Voltage: 1-Phase / 3-Phase 200230 VAC
Rated Output Current: 7.3 Arms
Safety Feature: Includes Safe Torque Off (STO) to ensure the motor stops safely in emergencies.

Key Difference from B2 Series

If you are replacing a B2 series driver, the E3 is about 20% smaller, offers much better auto-tuning (it learns your machine's weight automatically), and handles the high-resolution 24-bit encoder which the B2 cannot.
