ECMA-C11330R4 Delta Servo Motor 3000W L , Torque Nm - 9.55 , RPM - 3000

Name: ECMA-C11330R4 Delta Servo Motor 3000W L , Torque Nm - 9.55 , RPM - 3000
Brand: Corbital Enterprise
Price: 52400.0 INR
Availability: InStock

Price 52400.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

ECMA-C11330R4 Delta Servo Motor 3000W L , Torque Nm - 9.55 , RPM - 3000 Specification

Sealed Type
Packing seal

Product Type
Servo Motor

Color
Black and Silver

Usage & Applications
Industrial Machinerry

Weight
1.5 Kilograms (kg)

Phase
Three Phase

Warranty
1 Year

Material
Aluminum

ECMA-C11330R4 Delta Servo Motor 3000W L , Torque Nm - 9.55 , RPM - 3000 Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About ECMA-C11330R4 Delta Servo Motor 3000W L , Torque Nm - 9.55 , RPM - 3000

The ASD-A2-3023-U is the matching 3.0 kW (3000W) servo drive for the high-power A2 series systems. It is engineered to provide precise control over high-torque motors in demanding industrial environments. [1, 2]

Core Specifications

Rated Power: 3000 Watts (3.0 kW).
Output Current: 13.4 Arms continuous.
Input Phase/Voltage: 3-phase, 200V 230V AC.
Frequency Response: 1 kHz for high-speed dynamic performance.
Safety Function: Built-in Safe Torque Off (STO) for hardware-level

The ECMA-C11330R4 is a high-power 3.0 kW (3000W) AC Servo Motor from Deltas high-performance ASDA-A2 series. It is a low-inertia motor built for precision and high dynamic response in heavy industrial machinery. [1, 2, 3, 4, 5]

Dimensions & Weight (Inches)

This motor uses a 130 mm frame size to handle its significant power and torque output. [1, 2]

Dimension [1, 2, 3, 4, 5]	Inches	Millimeters
Width	5.12"	130 mm
Height	5.12"	130 mm
Net Weight	20.28 lbs	9.2 kg

Note: The R4 model is designed without a brake and includes an oil seal for protection against industrial fluids. [1, 2]

Function & Performance

Precision Control: Equipped with a 20-bit incremental encoder, providing 1,280,000 pulses per revolution for high-accuracy positioning.
Torque Capacity: Provides a rated torque of 9.55 Nm, with a high peak instantaneous torque of 28.65 Nm for handling heavy start-stop loads.
Dynamic Speed: Maintains a rated speed of 3,000 RPM, with a maximum capability of 4,500 RPM.
Industrial Rating: Features IP65 protection, making it resistant to dust and low-pressure water jets.
