ECMA-F11845RS Delta Servo Motor 4500W H , Torque Nm - 28.65 , RPM - 1500

Name: ECMA-F11845RS Delta Servo Motor 4500W H , Torque Nm - 28.65 , RPM - 1500
Brand: Corbital Enterprise
Price: 81400.0 INR
Availability: InStock

Price 81400.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

ECMA-F11845RS Delta Servo Motor 4500W H , Torque Nm - 28.65 , RPM - 1500 Specification

Sealed Type
Packing seal

Product Type
Servo Motor

Color
Black and Silver

Usage & Applications
Industrial Machinerry

Weight
5.5 Kilograms (kg)

Phase
Three Phase

Warranty
1 Year

Material
Aluminum

ECMA-F11845RS Delta Servo Motor 4500W H , Torque Nm - 28.65 , RPM - 1500 Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About ECMA-F11845RS Delta Servo Motor 4500W H , Torque Nm - 28.65 , RPM - 1500

Control & Motion Intelligence

Control Modes: Position, Speed, and Torque (switchable via I/O or communication).
Feedback Resolution: Supports 20-bit incremental encoders (1,280,000 pulses/rev) and 17-bit absolute encoders.
Electronic Cam (E-CAM): Built-in logic with up to 720 points for master-slave synchronization.
Specialized "U" Features: Supports high-speed digital command execution and includes an extension port for additional digital inputs.

Suppression & Safety

Vibration Suppression: Dual low-frequency vibration filters to eliminate mechanical shaking in large-scale machinery.
Resonance Suppression: Features advanced high-frequency auto-notch filters.
Safety Function: Built-in Safe Torque Off (STO), ensuring hardware-level power cut-off for operator safety (SIL2/PL d).

The ECMA-F11845RS is the highest-power motor in the 220V ASDA-A2 range, delivering 4.5 kW (4500W). As a High Inertia motor, it is designed for heavy-duty industrial applications that require maximum torque and stability at 1,500 RPM.

Dimensions & Weight (Inches)

This motor utilizes the large 180 mm frame size to accommodate the substantial internal windings and heat dissipation required for 4.5 kW.

Dimension	Inches	Millimeters
Width	7.09"	180 mm
Height	7.09"	180 mm
Length (Body Only)	9.27"	235.5 mm
Total Length (with Shaft)	12.38"	314.5 mm
Shaft Diameter	1.378"	35 mm
Net Weight	56.44 lbs	25.6 kg

Function & Performance

Extreme Torque: Delivers a massive rated torque of 28.65 Nm and a peak instantaneous torque of 71.62 Nm, making it the "powerhouse" for large-scale industrial presses, heavy gantry systems, and large CNC machines.
High Inertia Stability: Specifically functional for controlling extremely heavy mechanical loads. The high rotor inertia provides superior resistance to external disturbances and ensures ultra-smooth motion under heavy stress.
Precision: Features the standard 20-bit incremental encoder (1,280,000 pulses/rev) for high-resolution positioning despite its massive size.
Industrial Build: Rated IP65 with a built-in oil seal, ensuring reliability in harsh factory environments where heavy oils and dust are present.
