ECMA-FA1830SS Delta Servo Motor 3000W H , Torque Nm - 19.1 , RPM - 1500

Name: ECMA-FA1830SS Delta Servo Motor 3000W H , Torque Nm - 19.1 , RPM - 1500
Brand: Corbital Enterprise
Price: 98500.0 INR
Availability: InStock

Price 98500.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

ECMA-FA1830SS Delta Servo Motor 3000W H , Torque Nm - 19.1 , RPM - 1500 Specification

Sealed Type
Packing seal

Product Type
Servo Motor

Usage & Applications
Industrial Machinerry

Color
Black and Silver

Weight
22.5 Kilograms (kg)

Warranty
1 Year

Phase
Three Phase

Material
Aluminum

ECMA-FA1830SS Delta Servo Motor 3000W H , Torque Nm - 19.1 , RPM - 1500 Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About ECMA-FA1830SS Delta Servo Motor 3000W H , Torque Nm - 19.1 , RPM - 1500

The Delta ECMA-FA1830SS is a heavy-duty 3000W AC servo motor designed for "High-Torque, Low-Speed" applications. Its primary function is to move and hold extremely heavy loads with pinpoint precision.

Core Functions

High Torque Output: It delivers a massive 19.10 Nm of continuous torque at a rated speed of 1500 RPM. This makes it the "muscle" for heavy industrial equipment that requires consistent force rather than high speed.
Maximum Load Stability (Medium-High Inertia): The "FA" series features higher rotor inertia. This acts as a stabilizer, preventing the motor from vibrating or overshooting when moving massive mechanical structures like heavy bridge mills or large gantry systems.
Absolute Position Tracking: Equipped with a 17-bit absolute encoder, it provides 131,072 pulses per revolution. It "remembers" its exact physical location even after a power failure, meaning you never have to perform a "homing" sequence to reset the machine.
Safety Static Braking: The "SS" suffix indicates an integrated electromagnetic brake. Its function is to lock the shaft firmly in place (with a holding torque of at least 25 Nm) when the power is cut, which is critical for vertical axes to prevent heavy tools from falling.

Typical Applications

Large CNC Boring & Milling: Ideal for driving the primary axes of large-scale machine tools where cutting resistance is high.
Heavy-Duty Indexing: Used in rotary tables or tool changers that must rotate heavy workpieces to exact angles.
Material Forming: Controlling the stroke of industrial presses or large injection molding machines.

Drive Compatibility

This motor is typically paired with the ASDA-A2-3023-M servo drive. This combination allows for advanced functions like E-CAM (Electronic Cam) for synchronized multi-axis motion and Full Closed-Loop Control to eliminate mechanical backlash.

The physical specifications for the Delta ECMA-FA1830SS (3000W high-torque model with brake) in inches and pounds are as follows:

Dimensions & Weight

Attribute [1, 3, 4, 5, 7, 8]	Measurement (Inches)	Measurement (Metric)
Total Length	9.26 in	235.3 mm
Height (Frame)	7.09 in	180 mm
Width (Frame)	7.09 in	180 mm
Shaft Diameter	1.378 in	35 mm
Net Weight	49.60 lbs	22.5 kg

Key Technical Notes

Medium-High Inertia: The "FA" series is a Medium-High Inertia motor. This provides superior stability for heavy industrial loads that might cause vibrations in low-inertia motors.
High Torque at Lower Speed: Unlike the 3000W "CA" or "EA" models, this motor is rated for 1500 RPM, allowing it to produce a higher rated torque of 19.10 Nm.
Integrated Brake: The "SS" suffix indicates it includes an electromagnetic holding brake. This adds significant weight, bringing the total to nearly 50 lbs.
Mounting: The mounting hole spacing for this 180mm frame is approximately 7.874 inches (200 mm). [1, 2, 3, 4, 5, 6]

Function

This motor functions as a powerhouse for applications requiring heavy lifting or high constant force. Its absolute 17-bit encoder ensures high-precision positioning (131,072 pulses/rev) without needing to home the machine after every power cycle
