ECMA-K11320RS Delta Servo Motor 2000W M , Torque Nm - 9.55 , RPM - 2000

Name: ECMA-K11320RS Delta Servo Motor 2000W M , Torque Nm - 9.55 , RPM - 2000
Brand: Corbital Enterprise
Price: 48000.0 INR
Availability: InStock

Price 48000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

ECMA-K11320RS Delta Servo Motor 2000W M , Torque Nm - 9.55 , RPM - 2000 Specification

Torque
9.55 N-m

Sealed Type
Packing seal

Product Type
Servo Motor

Speed
2000 RPM

Usage & Applications
Industrial Machinerry

Color
Black and Silver

Weight
7.8 Kilograms (kg)

Phase
Three Phase

Warranty
1 Year

Material
Aluminum

IP Rating
Ip21

ECMA-K11320RS Delta Servo Motor 2000W M , Torque Nm - 9.55 , RPM - 2000 Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About ECMA-K11320RS Delta Servo Motor 2000W M , Torque Nm - 9.55 , RPM - 2000

The Delta ECMA-K11320RS functions as a high-precision actuator for 400V industrial systems that require exceptional stability when moving heavy or fluctuating loads. [1, 2]

Core Functions

Load Balancing (Medium Inertia): Unlike low-inertia motors that can jitter under heavy weight, this motor's medium-inertia design provides a mechanical dampening effect. This makes it ideal for machinery with high mechanical resonance or varying payloads.
High-Resolution Feedback: Equipped with a 20-bit incremental encoder, it delivers 1,280,000 pulses per revolution. This high resolution ensures smooth, stable rotation even at extremely low speeds, perfect for delicate manufacturing processes.
Precision Control Features: When paired with a Delta A2 drive, it supports:
- Electronic Cam (E-CAM): Up to 720 points for complex synchronized motions like rotary cut-offs or flying shears.
- Vibration Suppression: Built-in filters automatically minimize vibrations at machine edges, particularly useful in crane or gantry control.
- Full Closed-Loop Control: Direct interface for external linear scales to compensate for mechanical backlash and ensure edge-to-edge accuracy. [1, 2, 3, 4, 5]

Typical Applications

CNC Machinery: Precision milling, cutting, and boring axes where constant torque (9.55 Nm) is critical.
Automated Production: High-speed packaging, textile machines, and synchronized conveyor systems.
Robotics: Powering robotic arm joints that handle varying weights and require repeatable positioning. [1, 2, 4, 5]

The physical dimensions and weight for the Delta ECMA-K11320RS (2000W / 2kW model without brake) in inches and pounds are as follows:

Dimensions & Weight

Attribute [1, 2, 3, 4]	Measurement (Inches)	Measurement (Metric)
Total Length	7.38 in	187.5 mm
Height (Frame)	5.118 in	130 mm
Width (Frame)	5.118 in	130 mm
Shaft Diameter	0.866 in	22 mm
Shaft Length	2.165 in	55 mm
Net Weight	17.20 lbs	7.8 kg

Key Technical Notes

Medium Inertia Performance: As a "K" series motor, it features medium inertia, providing better stability for mechanical loads with higher resonance compared to low-inertia models.
Frame Size: It utilizes a standard 130 mm square frame, optimized for a balance of power and space efficiency.
Brake Status: The "RS" suffix indicates this unit is without a brake. This makes it lighter and shorter than the "SS" (with brake) version.
High-Resolution Feedback: Equipped with a 20-bit incremental encoder, offering 1,280,000 pulses per revolution for precise motion control.
Mounting: The standard mounting hole spacing for this frame is 5.709 inches (145 mm). [1, 2, 3, 4, 5]
