ECMA-KA1320SS Delta Servo Motor 2000W M , Torque Nm - 9.55 , RPM - 2000

Name: ECMA-KA1320SS Delta Servo Motor 2000W M , Torque Nm - 9.55 , RPM - 2000
Brand: Corbital Enterprise
Price: 99800.0 INR
Availability: InStock

Price 99800.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

ECMA-KA1320SS Delta Servo Motor 2000W M , Torque Nm - 9.55 , RPM - 2000 Specification

Sealed Type
Packing seal

Product Type
Servo Motor

Usage & Applications
Industrial Machinerry

Color
Black and Silver

Weight
9.5 Kilograms (kg)

Warranty
1 Year

Phase
Three Phase

Material
Aluminum

ECMA-KA1320SS Delta Servo Motor 2000W M , Torque Nm - 9.55 , RPM - 2000 Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About ECMA-KA1320SS Delta Servo Motor 2000W M , Torque Nm - 9.55 , RPM - 2000

The Delta ECMA-KA1320SS is a robust 2000W (2 kW) medium-inertia AC servo motor from the ASDA-A2 Series, featuring an integrated brake and absolute encoder for high-torque industrial applications. [1, 2]

Dimensions & Weight

Weight: 20.94 lbs (9.5 kg).
Length: 8.50 inches (216 mm).
Width (Frame Size): 5.12 inches (130 mm).
Height (Frame Size): 5.12 inches (130 mm). [1, 2, 3, 4, 5]

Core Specifications

Rated Output Power: 2.0 kW (2000W).
Rated Torque: 9.55 Nm (Peak torque up to 28.65 Nm).
Rated Speed: 2000 RPM (Maximum speed up to 3000 RPM).
Input Voltage: 400V AC.
Encoder Type: 17-bit Absolute encoder (131,072 pulses/rev).
Brake: Included (Integrated electromagnetic brake).
Protection: IP65 (Dust-tight and protected against water jets). [1, 2, 3, 4, 5]

Shaft & Mounting

Shaft Diameter: 0.87 inches (22 mm).
Shaft Length: 2.17 inches (55 mm).
Mounting Hole Spacing: 5.71 inches (145 mm). [1, 2, 3, 4, 5]

Functionality

This motor excels in driving large loads with high inertia, such as large CNC mill axes or heavy-duty conveyors. The "KA" designation indicates it is a Medium Inertia model, which provides better stability and reduces oscillation when moving heavy mechanical assemblies. The integrated brake ensures safety in vertical applications by holding the load in place if power is lost. [1, 2, 3]
