GD20-1R5G-S2 - INVT VFD 1.5 kW / 2HP 230V

Name: GD20-1R5G-S2 - INVT VFD 1.5 kW / 2HP 230V
Brand: Corbital Enterprise
Price: 7000.0 INR
Availability: InStock

Price 7000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

GD20-1R5G-S2 - INVT VFD 1.5 kW / 2HP 230V Specification

IP Rating
20

Mounting Type
DIN-rail mounting

Feature
Industrial Connectivity

Humidity %
5% to 95%

Product Type
VFD

Power Rating
220V (-15%) to 240V (+10%)

Application
Industrial Machinery

Color
Black

Rated Voltage
220V (-15%) to 240V (+10%) Volt (V)

Weight
1..2 Kilograms (kg)

Usage & Applications
Industrial Machinery

Warranty
1 Year

Input Voltage
220V (-15%) to 240V (+10%) Volt (V)

Phase
3 Phase

Material
Plastic

Rated Current
220V (-15%) to 240V (+10%) Volt (v)

Features
Excellent Vector Performance

GD20-1R5G-S2 - INVT VFD 1.5 kW / 2HP 230V Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About GD20-1R5G-S2 - INVT VFD 1.5 kW / 2HP 230V

The

INVT GD20-1R5G-S2

is a 1.5 kW (2 HP) Variable Frequency Drive (VFD) from the Goodrive20 series. It is a high-performance mini vector drive designed for single-phase 230V input and 3-phase output.

Manufacturer:	INVT
Series:	GD20-UL
Model:	GD20-1R5G-S2-UL
Application:	general purpose
Capacity, kW:	1.5
Current, :	7.5
Main power supply, V:	220-240
Phase:	1
Output frequency, Hz:	0-400
Enclosure:	IP20
Overload capacity, % per 1 min.:	150
EMC filter:	optional EMI filter
Analog input:	1
Digital input:	5
Analog output:	2
Digital output:	1
Relay output:	2
RS485 (Modbus RTU):	RS485
Starting torque:	0.5 Hz / 150% (SVC)
V/f control mode:	+
Sensorless vector control:	+
Operation temperature, :	-10.....+50
Dimensions (W x H x D), mm:	80x185x140,5
Weight, kg:	1,4

Height: 7.28 inches (185 mm)
Width: 3.15 inches (80 mm)
Depth (Length): 5.53 inches (140.5 mm)
Weight: Approximately 2.65 lbs (1.2 kg)
