GD200A-015G/018P-4 INVT VFD 15 kW / 20HP 415V

Name: GD200A-015G/018P-4 INVT VFD 15 kW / 20HP 415V
Brand: Corbital Enterprise
Price: 23200.0 INR
Availability: InStock

Price 23200.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

GD200A-015G/018P-4 INVT VFD 15 kW / 20HP 415V Specification

Feature
Sensorless Vector Control

Humidity %
5% to 95%

IP Rating
20

Mounting Type
DIN-rail mounting

Product Type
VFD

Power Rating
220V (-15%) to 240V (+10%)

Application
Industrial Machinery

Color
Black

Weight
6 Kilograms (kg)

Rated Voltage
220V (-15%) to 240V (+10%) Volt (V)

Usage & Applications
Industrial Machinery

Warranty
1 Year

Input Voltage
220V (-15%) to 240V (+10%) Volt (V)

Phase
3 Phase

Rated Current
220V (-15%) to 240V (+10%) Volt (v)

Features
Connectivity

Material
Plastic

GD200A-015G/018P-4 INVT VFD 15 kW / 20HP 415V Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About GD200A-015G/018P-4 INVT VFD 15 kW / 20HP 415V

The INVT GD200A-015G/018P-4 is a high-performance 15 kW (20 HP) / 18.5 kW (25 HP) Variable Frequency Drive. Like other models in the GD200A series, it features a dual-power rating to handle different industrial load types:

G (General/Heavy Duty): 15 kW / 20 HP for constant torque loads (32 A output).
P (Pump/Normal Duty): 18.5 kW / 25 HP for variable torque loads like fans and pumps (38 A output)

Manufacturer:	INVT
Series:	GD 200A
Model:	GD200A-015G/018P-4
Application:	general purpose
Capacity, kW:	15/18,5
Current, :	32/38
Main power supply, V:	400
Phase:	3
Output frequency, Hz:	0-400
Enclosure:	IP20
Overload capacity, % per 1 min.:	150

Physical Dimensions & Weight

This model uses the same Frame 5 enclosure as the 11 kW and 7.5 kW units, keeping the footprint consistent for easier panel upgrades.

Height: 12.60 inches (320 mm)
Width: 6.69 inches (170 mm)
Depth: 7.73 inches (196.3 mm)
Net Weight: Approximately 13.23 lbs (6.0 kg)

Key Features

Performance: Uses Sensorless Vector Control (SVC) to provide high starting torque (150% at 0.5 Hz) and precise speed accuracy.
Hardware: Includes a standard built-in C3 EMC filter to reduce noise and an integrated braking unit (chopper) for quick stopping.
Durability: Independent air duct design and thickened conformal coating protect internal components from industrial dust and humidity.
Connectivity: Supports Modbus RTU communication via RS485 and features a detachable keypad with parameter copy functions.
