MCDLN35SE - A6SE Panasonic A6 750W Driver

About MCDLN35SE - A6SE Panasonic A6 750W Driver

Electrical Specifications

• Series: MINAS A6SE
• Rated Motor Power: 750 W
• Supply Voltage: 200 V AC (single/3-phase)
• Output Current: 22 A class
• Frequency Response: 3.2 kHz
• Control Mode: Position control only

---

Control Functions (What it does)

1. Position Control (Main Function)

• Receives pulse commands (STEP/DIR)
• Moves motor to exact position
• Used in CNC, robotics, automation

---

2. Speed Control (basic mode)

• Maintains commanded speed
• Adjusts automatically under load

---

3. Torque Limiting (indirect)

• Protects motor and machine
• Prevents overload conditions

---

4. Closed-Loop Feedback Control

• Reads encoder feedback (23-bit resolution)
• Continuously corrects position error
• Ensures precise and stable motion

---

System Role

In a servo system:

• Motor = muscle
• Driver (MCDLN35SE) = brain + power amplifier
• Encoder = feedback sensor (eyes)

---

Key Features

• Ultra-fast 3.2 kHz response
• Compact design
• Auto tuning support
• Built-in regenerative control
• No safety STO function (basic version)
• No network communication (only pulse control)

---

Applications

• CNC machines
• Pick & place systems
• Conveyor automation
• Packaging machines
• Industrial motion systems

---

Physical Size (for reference)

• Height: 5.91 in
• Width: 2.56 in
• Depth: 6.69 in
• Weight: 3.5 lb

---

Simple One-Line Meaning

MCDLN35SE is a basic 750W servo driver that converts pulse commands into precise motor motion using encoder feedback for industrial automation control.

---

Key Difference (SE vs SG vs SF vs NE)

• SE: simplest (pulse only)
• SG: adds RS485/Modbus communication
• SF: advanced + safety + multi-function
• NE: high-speed RTEX network system

  Function of Panasonic MCDLN35SE (A6SE 750W Servo Driver)

  This device is a servo amplifier (driver). Its main function is to control a 750W servo motor by converting electrical commands into precise motion with feedback correction.

  ---

  Core Function

  It takes pulse commands from a PLC/CNC controller and converts them into controlled motor movement (position, speed, torque).

  ---

  What it actually does

  1. Position Control (Main Function)

  • Moves motor shaft to exact commanded position
  • Counts pulses (STEP/DIR input)
  • Ensures high repeatability in motion

  ---

  2. Speed Control

  • Maintains required rotation speed
  • Automatically adjusts torque when load changes
  • Keeps motion smooth and stable

  ---

  3. Torque Limiting

  • Controls motor force output indirectly
  • Protects machine from overload or mechanical damage

  ---

  4. Closed-Loop Feedback Control

  • Reads 23-bit encoder feedback from motor
  • Compares actual vs commanded position
  • Corrects error instantly (real-time control)

  ---

  System Role

  In a servo system:

  • Motor = muscle (movement source)
  • Driver = brain + power amplifier
  • Encoder = feedback sensor (accuracy control)

  ---

  Additional Functions

  • Auto tuning (automatic parameter adjustment)
  • Vibration suppression (smooth motion control)
  • Basic internal positioning functions
  • Regenerative braking control

  ---

  Where it is used

  • CNC machines
  • Robotics systems
  • Packaging machines
  • Conveyor automation
  • Pick & place machines

  ---

  Simple One-Line Meaning

  MCDLN35SE is a 750W servo driver that converts pulse commands into precise, controlled motor motion using encoder feedback for accurate industrial automation.

Reliable Performance for Industry

The A6SE Panasonic 750W Driver stands out for its stable performance in demanding industrial environments. Its robust design and three-phase compatibility make it suitable for a range of machinery, delivering consistent power and efficiency. The included one-year warranty provides added confidence in its quality and longevity.


Smart Design and Durable Build

With a compact, lightweight build at just 1.15 kg and crafted from high-grade plastic, this driver is both easy to install and resilient against the rigors of industrial use. The sleek black and silver aesthetic pairs well with modern equipment, ensuring it fits seamlessly into your machinery setup.
