Price 19400.0 INR/ Number

MOQ : 1 Number

MD290T5.5G/7.5P-INT AC Drive, Three Phase, 380 to 480V, 5.5/7.5kw - Inovance Ac Drive Specification

  • Product Type
  • VFD
  • Application
  • Industrial Machinerry
  • Color
  • Gray or Black
  • Weight
  • 4.3 Kilograms (kg)
  • Usage & Applications
  • Industrial Machinerry
  • Warranty
  • 1 Year
  • Phase
  • 3 Phase
  • Material
  • Polycarbonate


MD290T5.5G/7.5P-INT AC Drive, Three Phase, 380 to 480V, 5.5/7.5kw - Inovance Ac Drive Trade Information

  • Minimum Order Quantity
  • 1 Number
  • Delivery Time
  • 24 Hours


About MD290T5.5G/7.5P-INT AC Drive, Three Phase, 380 to 480V, 5.5/7.5kw - Inovance Ac Drive

The Inovance MD290T5.5G/7.5P-INT is a three-phase variable-frequency AC drive engineered for general-purpose open-loop speed and torque regulation of three-phase industrial asynchronous induction motors. [1, 2, 3, 4]
Core Functional Capabilities
  • Dual-Rating Architecture: Adapts dynamically across two distinct industrial load classes.
  • Heavy Duty Rating (G): Drives constant-torque automation loads up to 5.5 kW (7.5 HP) with 150% overload capacity for 60 seconds.
  • Normal Duty Rating (P): Powers variable-torque applications (such as large industrial fans or centrifugal pumps) up to 7.5 kW (10 HP) with 110% overload protection for 60 seconds.
  • Control Platform: Employs open-loop V/F control alongside automatic torque boost, automatic slip compensation, and four independent programmable S-ramps.
  • Integrated Braking: Features a built-in braking unit to attach an external braking resistor directly for high-inertia motor deceleration. [1, 2, 3, 5]
Weight & Engineering Dimensions
This physical rating shifts the unit into the T4 Frame Size engineering layout. [1, 2, 3]
The official outer dimensions converted to inches and dry equipment weight are: [1]
  • Height: 11.02 inches (280 mm)
  • Width: 7.09 inches (180 mm)
  • Depth (Length): 6.69 inches (170 mm)
  • Total Operational Weight: 9.48 lbs (4.3 kg) [1, 2, 3]
