MGMF442L1G6M Torque Nm - 28, Fram Size- 176mm , RPM - 3000

Price 89000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

MGMF442L1G6M Torque Nm - 28, Fram Size- 176mm , RPM - 3000 Specification

Sealed Type
Packing seal

Product Type
Servo Motor

Color
Black and Silver

Usage & Applications
Industrial Machinery

Weight
21 Kilograms (kg)

Phase
Three Phase

Warranty
1 Year

Material
Aluminum

MGMF442L1G6M Torque Nm - 28, Fram Size- 176mm , RPM - 3000 Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About MGMF442L1G6M Torque Nm - 28, Fram Size- 176mm , RPM - 3000

The Panasonic MINAS A6 MGMF442L1G6M is a high-output 4.4 kW (4400 W) middle inertia AC servo motor. In the 176 mm frame family, this model offers a significant jump to 28 Nm of torque, making it a "heavy-lifter" for high-speed industrial axes.

Core Technical Specifications

Rated Output: 4400 W (4.4 kW).
Rated Torque: 28.0 Nm.
Peak Torque: 84.0 Nm.
Rated Speed: 1500 r/min.
Maximum Speed: 3000 r/min.
Rated Current: 26.0 A (rms).
Voltage: 200 V AC.

Physical Dimensions (Inches)

Width & Height (Flange): 6.93" (176 mm square).
Body Length: 8.35" (212 mm).
Total Length (Body + Shaft): 11.46" (291 mm).
Weight: Approximately 46.3 lbs (21.0 kg).
Shaft Diameter: 1.38" (35 mm).

Key Features

High Torque Density: Delivering 28 Nm in a 176 mm frame, it provides massive force for heavy-duty ball screws and large-scale mechanical drives.
Middle Inertia Stabilization: Designed to handle loads with high mechanical resonance, ensuring smooth motion even when the load weight varies.
23-bit Absolute Encoder: Features the standard A6 high-resolution feedback (8.38 million pulses/rev) for surgical precision.
Protection: IP67 rated, fully sealed against dust and high-pressure water/oil spray.
G6M Design: This specific model is without a holding brake.

The Panasonic MGMF442L1G6M functions as an Extra-High Torque Prime Mover. At 4.4 kW, it is designed to provide massive "muscular" force for heavy-duty industrial axes that require high-speed movement without losing accuracy.

1. Massive Mechanical Drive (Power Function)

The primary function is the delivery of 28.0 Nm of continuous torque.

High Force Output: It maintains this 28 Nm force at its rated speed (1500 RPM), allowing it to drive massive ball screws or heavy industrial belt systems.
84 Nm Peak "Punch": It can provide a momentary burst of 84 Nm (3x its rating). This is critical for overcoming "stiction" (static friction) when starting a multi-ton machine from a dead stop or for rapid, aggressive accelerations.

2. Stability for Massive Loads (Middle Inertia)

This motor is a Middle Inertia type, which serves a specific damping function:

Mechanical Stabilizer: The internal rotor has significant mass, which acts as a "gyroscope." This functions to prevent the machine from "shaking" or vibrating when it is attached to a load that is much heavier than the motor itself.
Resonance Suppression: It is ideal for machines where the load weight varies, as the motor's own inertia keeps the control loop stable and predictable.

3. Surgical Precision at Scale

Despite its 46 lb weight, its function is high-resolution tracking:

23-bit Position Feedback: It monitors its position at 8,388,608 unique points per revolution. This allows a 4.4 kW machine to position tools with a precision thinner than a human hair.
Absolute Memory: It functions to "remember" its location. You never need to "home" the machine because the motor tracks its mechanical position even when the power is off.

4. Heavy-Duty Mechanical Interface

35mm Reinforced Shaft: The shaft is extra thick to function as a bridge for the 84 Nm peak torque without twisting or snapping under extreme stress.
IP67 Sealing: It is designed to function in "wet" areas. It is fully protected against dust and can be sprayed with high-pressure oils or coolants inside a CNC machining center.

Typical Applications

Large CNC Boring & Milling: Driving the primary X or Y axis of machines used for mining or aerospace parts.
Industrial Presses: Providing precise depth control for heavy metal forming.
Material Handling: Moving heavy automotive chassis or steel pallets at high speed.
