SC3-043-18.5K/22KF Shihlin AC Drive 440V

Name: SC3-043-18.5K/22KF Shihlin AC Drive 440V
Brand: Corbital Enterprise
Price: 22500.0 INR
Availability: InStock

Price 22500.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

SC3-043-18.5K/22KF Shihlin AC Drive 440V Specification

Product Type
VFD

Application
Industrial Machinerry

Color
Charcoal Black

Usage & Applications
Industrial Machinerry

Weight
5 Kilograms (kg)

Warranty
1 Year

Phase
3 Phase

Material
Polycarbonate

SC3-043-18.5K/22KF Shihlin AC Drive 440V Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About SC3-043-18.5K/22KF Shihlin AC Drive 440V

The Shihlin SC3-043-18.5K/22KF AC Drive is a high-capacity, dual-rated inverter built for demanding industrial automation. It is rated for 18.5 kW (25 HP) in heavy-duty applications or 22 kW (30 HP) for normal-duty loads, operating on a 440V AC (380-480V) three-phase supply. [1, 2, 3, 4]

Core Functions & Features

According to the Shihlin SC3 User Manual, its primary functions include:

Dual Rating System:
- Heavy Duty (18.5K): Ideal for high-torque loads like extruders and crushers.
- Normal Duty (22KF): Optimized for variable torque loads like centrifugal fans and pumps.
High-Performance Control: Features a 32-bit CPU for precise vector control, offering high stability at low frequencies.
Integrated Protection: Includes comprehensive safeguards against overcurrent, overvoltage, motor stalling, and overheating.
Process Automation: Built-in PID feedback control for automated pressure or flow regulation.
Communication: Dual RS-485 interfaces supporting MODBUS protocol (up to 115200 bps). [1, 2, 3, 4, 5]

Physical Specifications (Frame E)

This model uses the larger Frame E chassis to handle higher power requirements. Dimensions derived from Shihlin technical data and IndiaMART include: [1, 2]

Specification [1, 2]	Metric Measurement	Imperial Measurement (Approx.)
Weight	4.0 kg to 5.8 kg*	8.8 lbs to 12.8 lbs*
Height (H)	250 mm	9.84 inches
Width (W)	160 mm	6.30 inches
Depth (D)	160 mm	6.30 inches
*Note: Shipping weight typically includes packaging; the 5.8 kg figure is often cited for the unit plus standard accessories.
