SC3-043-5.5K Shihlin AC Drive 440V

Name: SC3-043-5.5K Shihlin AC Drive 440V
Brand: Corbital Enterprise
Price: 14000.0 INR
Availability: InStock

Price 14000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

SC3-043-5.5K Shihlin AC Drive 440V Specification

Humidity %
90

IP Rating
20

Product Type
VFD

Application
Industrial Machinerry

Color
Charcoal Black

Usage & Applications
Industrial Machinerry

Weight
1.5 Kilograms (kg)

Warranty
1 Year

Phase
3 Phase

Material
Polycarbonate

SC3-043-5.5K Shihlin AC Drive 440V Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About SC3-043-5.5K Shihlin AC Drive 440V

The Shihlin SC3-043-5.5K AC Drive is a high-performance compact inverter designed for motors up to 5.5 kW (7.5 HP). It operates on a 440V AC (380-480V) three-phase power supply and is widely used for industrial motor speed control in applications such as conveyors, pumps, fans, and compressors.

Core Functions & Features

According to the Shihlin SC3 User Manual and Shihlin Electric Global, its primary features include:

Vector Control: Provides high starting torque and precise speed regulation for stability across various loads.
High Efficiency: Operates at approximately 98% efficiency, promoting significant energy savings.
Built-in Protection: Safeguards against overcurrent, overvoltage, stalling, and overheating.
PID Control: Includes a built-in PID feedback mechanism for maintaining constant pressure or flow.
Communication: Dual RS-485 interfaces supporting MODBUS protocol for system integration. [1, 2]

Physical Specifications (Frame B)

The 5.5K model typically utilizes the Frame B housing to manage its higher power output while maintaining a compact footprint. [1, 2]

Specification [1, 2, 3, 4, 5]	Metric Measurement	Imperial Measurement (Approx.)
Weight	1.42 kg to 3.5 kg*	3.13 lbs to 7.7 lbs*
Height (H)	185 mm	7.28 inches
Width (W)	112 mm	4.41 inches
Depth (D)	165 mm	6.50 inches
*Note: Net unit weight is 1.42 kg, while 3.5 kg represents the shipping weight.
