VFX48- 030-20 - Crompton VFD - 11kW / 15HP 3-Phase 380-480

Name: VFX48- 030-20 - Crompton VFD - 11kW / 15HP 3-Phase 380-480
Brand: Corbital Enterprise
Price: 38900.0 INR
Availability: InStock

Price 38900.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

VFX48- 030-20 - Crompton VFD - 11kW / 15HP 3-Phase 380-480 Specification

Product Type
VFD

Application
Industrial Machinerry

Color
Gray or Black

Weight
17 Kilograms (kg)

Usage & Applications
Industrial Machinerry

Warranty
1 Year

Phase
3 Phase

Material
Polycarbonate

VFX48- 030-20 - Crompton VFD - 11kW / 15HP 3-Phase 380-480 Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About VFX48- 030-20 - Crompton VFD - 11kW / 15HP 3-Phase 380-480

The CG Emotron VFX48-030-20 is an upgraded 30-Amp model in the same product line. Because both models share the exact same C2 frame size, it retains the identical external dimensions and weight despite providing more power. [1, 2]

Core Technical Specifications

Parameter [1, 2, 3, 4]	Specification Details
Model Number	VFX48-030-20
Input Voltage	3-Phase, 380V to 480V AC (10%), 50/60 Hz
Heavy-Duty Power Rating	11 kW / 15 HP
Normal-Duty Power Rating	15 kW / 20 HP
Rated Output Current	30 A (Nominal) \| 45 A Max for 60 seconds
Enclosure Rating	IP20 (Panel mount)
Frame Size	C2

Physical Dimensions and Weight

Weight: 37.5 lbs / 17 kg
Height (Length): 19.53 in / 496 mm
Width: 6.57 in / 167 mm
Depth: 10.51 in / 267 mm [1, 3]

Application & Upgrading Note

Because this drive matches the physical footprint of the 025-20 model, it serves as a direct drop-in physical replacement if you are upgrading a motor circuit or need a slightly higher continuous current head-room (30 Amps vs 25 Amps) within the same enclosure space. [1]
