VSR23-7p5 - Crompton VFD - 1.5 kW / 2HP 1-Phase 220V Solar

Name: VSR23-7p5 - Crompton VFD - 1.5 kW / 2HP 1-Phase 220V Solar
Brand: Corbital Enterprise
Price: 8600.0 INR
Availability: InStock

Price 8600.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

VSR23-7p5 - Crompton VFD - 1.5 kW / 2HP 1-Phase 220V Solar Specification

Product Type
VFD

Application
Industrial Machinerry

Color
Gray or Black

Usage & Applications
Polycarbonate

Weight
1.5 Kilograms (kg)

Warranty
1 Year

Phase
1 Phase

Material
Industrial Machinerry

VSR23-7p5 - Crompton VFD - 1.5 kW / 2HP 1-Phase 220V Solar Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About VSR23-7p5 - Crompton VFD - 1.5 kW / 2HP 1-Phase 220V Solar

The Crompton Greaves Emotron VSR23-7P5 is a 1.5 kW (2 HP) Solar Variable Frequency Drive (VFD) engineered to regulate and power mid-sized solar water pumping systems. It operates using standard 220V single-phase grid power or direct DC voltage from a solar panel array to run your water pump efficiently. [1]

Physical Specifications (Dimensions & Weight)

This 1.5 kW (2 HP) drive uses the mid-sized Frame Size 2 (VSS2) chassis, matching the physical body profile of the 2.2 kW drive discussed earlier:

Height: 173 mm (6.81 inches)
Width: 110 mm (4.33 inches)
Depth / Length: 135 mm (5.31 inches)
Total Weight: 1.5 kg (3.31 lbs) [1]

Electrical & Technical Specifications

Power Rating: 1.5 kW / 2 HP
Maximum Output Current: 7.5 Amps
Grid AC Input Voltage: 220V240V AC (Single-Phase)
Maximum Solar DC Input Voltage: 400V DC
Recommended MPPT Range: 250V to 350V DC
Recommended Solar Array Power: 2.0 kWp to 2.2 kWp (to account for environmental power loss) [1, 2]

Core Protection & Operational Logic

Smart Hybrid Switching: Allows dual power inputs to run the pump on solar during peak daylight and switch seamlessly to grid power or a generator when clouds roll in.
Full Pump Protection Suite: Features automated dry-run prevention (detecting when the well runs out of water), over-current shutdown, motor short-circuit defense, and over-voltage safeguards.
Tank Level Management: Integrated terminals support water level sensor inputs to stop the pump automatically when your overhead storage tank is full.
