VSRE48-003 - Crompton VFD - 0.75 kW / 1HP 3-Phase 380V Solar

Name: VSRE48-003 - Crompton VFD - 0.75 kW / 1HP 3-Phase 380V Solar
Brand: Corbital Enterprise
Price: 9600.0 INR
Availability: InStock

Price 9600.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

VSRE48-003 - Crompton VFD - 0.75 kW / 1HP 3-Phase 380V Solar Specification

Product Type
VFD

Application
Industrial Machinerry

Color
Gray or Black

Usage & Applications
Industrial Machinerry

Weight
1.5 Kilograms (kg)

Warranty
1 Year

Phase
3 Phase

Material
Polycarbonate

VSRE48-003 - Crompton VFD - 0.75 kW / 1HP 3-Phase 380V Solar Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About VSRE48-003 - Crompton VFD - 0.75 kW / 1HP 3-Phase 380V Solar

The Crompton Greaves Emotron VSRE48-003 is a high-efficiency 0.75 kW (1 HP) Solar Variable Frequency Drive (VFD) configured for a 3-phase 380V480V system. Unlike the previous VSR23 models built on the small Frame 1 setup, this 380V model transitions into the Frame Size 2 (VSR2) enclosure footprint to accommodate higher voltage internal insulation clearances. [1, 2, 3, 5]

Physical Dimensions & Weight

Height: 173 mm (6.81 inches)
Width: 110 mm (4.33 inches)
Depth / Length: 135 mm (5.31 inches)
Total Weight: 1.5 kg (3.31 lbs) [1, 2, 3, 4]

Mounting Sizing (Center-to-Center Holes)

Mounting Hole Height (H1): 163 mm (6.42 inches)
Mounting Hole Width (W1): 100 mm (3.94 inches)
Installation Aperture Screw Diameter (d): 4.5 mm (0.18 inches) [1]

Electrical Configuration (VSRE48 Series)

Power Capacity: 0.75 kW / 1 HP
Rated Output Current: 2.5 Amps
Maximum Solar DC Input Voltage: 800V DC
Recommended Solar Array Window (Voc): 500V to 700V DC
Optimal MPPT Tracking Voltage Range: 450V to 600V DC
Grid AC Backup Input Supply: 3-Phase 380V to 480V AC (20% or -15% to +30%)
Recommended Solar Array Power: 1.1 kWp (Kilowatt-peak) to offset real-world heat and panel losses. [1, 4, 5]

Integrated System Protections

Dual Motor Support: Capable of running both standard AC Induction Motors and highly efficient Permanent Magnet Synchronous Motors (PMSM). [1]
Extreme Voltage Handling: Built-in high-threshold lightning protection, transient overvoltage clipping, and phase-loss isolation safeguards.
Sensorless Automation: Advanced sleep and wake cycles tied directly to the solar radiance levels to eliminate manually switching power over during cloudy intervals.
