ASD-E3-0721-L Delta Servo Driver 750W

Name: ASD-E3-0721-L Delta Servo Driver 750W
Brand: Corbital Enterprise
Price: 24100.0 INR
Availability: InStock

Price 24100.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

ASD-E3-0721-L Delta Servo Driver 750W Specification

Sealed Type
Packing seal

Product Type
Servo Motor

Usage & Applications
Industrial Machinerry

Color
Black and Silver

Weight
1.2 Kilograms (kg)

Phase
Three Phase

Warranty
1 Year

Material
Aluminum

ASD-E3-0721-L Delta Servo Driver 750W Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
24 Hours

About ASD-E3-0721-L Delta Servo Driver 750W

The ASD-E3-0721-L is a 750W high-performance AC servo drive from Deltas ASDA-E3 series, designed to match 750W motors like the ECM-B3H-C20807RS1. It is optimized for pulse-input (PT) mode and offers advanced control in a compact package. [1, 2, 4]

Technical Specifications

Feature [1, 2, 3, 5]	Specification
Rated Output Power	750 W
Input Power Supply	Single-phase / Three-phase 200230 VAC
Continuous Output Current	5.1 Arms
Max Output Current	14.14 Arms
Encoder Support	24-bit resolution (16.7 million pulses/rev)
Regenerative Resistor	Built-in (100 Ohm, 40W)
Safety Function	Built-in Safe Torque Off (STO) SIL2

Physical Dimensions & Weight

The E3 series is roughly 25% smaller than previous generations to save cabinet space.

Width: 60 mm (2.36 inches)
Height: 162 mm (6.38 inches)
Depth: 155.85 mm (6.14 inches)
Weight: 1.2 kg (2.64 lbs)

Key Functions

Position Control (PT Mode): Specifically built for external pulse commands (Pulse + Direction, CW/CCW, or A/B phase) with a max frequency of up to 4 Mpps.
Superior Tuning: Features automatic tuning that simplifies gain adjustment, even for systems with flexible mechanical structures.
Enhanced Performance: Boasts a 2.5 kHz response bandwidth, providing faster settling times compared to standard entry-level drives.
Vibration Control: Includes five sets of high-frequency notch filters (up to 5,000 Hz) to automatically detect and suppress mechanical resonance. [1, 2, 5]

You can typically find this drive starting at approximately 13,000 to 14,850 at IndiaMART or Maven Automation.

High-Efficiency Industrial Motor Control

The ASD-E3-0721-L Delta Servo Driver is engineered for seamless integration in industrial machinery, providing precise motor control and efficient energy usage. Its three-phase operation ensures stable performance even under demanding conditions, delivering consistent results for various automation tasks. The robust aluminum casing not only enhances durability but also facilitates effective heat dissipation during extended operations.

Designed for Reliability and Longevity

With a sealed packing design, the Delta Servo Driver is protected against dust and moisture, preserving its internal components for prolonged use. Its lightweight construction simplifies installation and maintenance, while the one-year warranty provides added assurance and support for businesses seeking reliable automation solutions.

FAQ's of ASD-E3-0721-L Delta Servo Driver 750W:

Q: How does the ASD-E3-0721-L Delta Servo Driver benefit industrial machinery?

A: The servo driver ensures precise control of motor speed and positioning, leading to greater accuracy in automated processes. Its reliable performance enhances equipment efficiency and minimizes operational downtime in industrial environments.

Q: What is the main usage of the ASD-E3-0721-L Delta Servo Driver?

A: This servo driver is primarily used to control motors in industrial machinery, supporting applications such as robotic arms, conveyors, and automated production lines that require precise movement and control.

Q: When should I consider replacing or servicing the servo driver?

A: Regular maintenance is recommended as per the manufacturer's guidelines. If you notice inconsistent motor performance, error signals, or overheating, it may be time to inspect or replace the driver. The one-year warranty provides an additional layer of coverage during the initial period of use.

Q: Where can I install the ASD-E3-0721-L Delta Servo Driver?

A: This servo driver is intended for installation within industrial environments, particularly in machines requiring three-phase motor control. Ensure the location is dry, well-ventilated, and free from excessive dust to maximize its lifespan.

Q: What is the installation process for this servo driver?

A: Installation involves connecting the servo driver to a compatible three-phase power source and the industrial motor to be controlled. It is advisable to follow the manufacturer's instructions and consult a certified technician for optimal setup and safety.

Q: How does the sealed type packaging protect the servo driver?

A: The packing seal keeps the servo driver's internal components shielded from dust, moisture, and other external contaminants during transport and storage, ensuring the device arrives in optimal condition and maintains its reliability.
