ECMA-C10602RS Delta Servo Motor 200W L , Torque Nm - 0.64 , RPM - 3000

Name: ECMA-C10602RS Delta Servo Motor 200W L , Torque Nm - 0.64 , RPM - 3000
Brand: Corbital Enterprise
Price: 20200.0 INR
Availability: InStock

Price 20200.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

ECMA-C10602RS Delta Servo Motor 200W L , Torque Nm - 0.64 , RPM - 3000 Specification

Sealed Type
Packing seal

Product Type
Servo Motor

Usage & Applications
Industrial Machinerry

Color
Black and Silver

Weight
1.2 Kilograms (kg)

Warranty
1 Year

Phase
Three Phase

Material
Aluminum

ECMA-C10602RS Delta Servo Motor 200W L , Torque Nm - 0.64 , RPM - 3000 Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About ECMA-C10602RS Delta Servo Motor 200W L , Torque Nm - 0.64 , RPM - 3000

The ECMA-C10602RS is a 200W AC Servo Motor from Delta Electronics, primarily designed for the ASDA-A2 series servo systems. It is a high-precision motor typically used in industrial automation, CNC machinery, and robotics. [1, 2, 3, 4, 5]

Key Specifications

Power Output: 200 Watts (0.2 kW).
Rated Speed: 3,000 RPM (Maximum speed up to 5,000 RPM).
Rated Torque: 0.64 Nm (Peak instantaneous torque of 1.92 Nm).
Brake: This specific model (RS) is without a brake.
Encoder: Features a 20-bit (or 17-bit depending on version) incremental encoder for precise feedback.
Frame Size: 60 mm.
Environmental Protection: Rated IP65 for the shaft, providing resistance to dust and low-pressure water jets. [1, 2, 3, 4, 5, 6, 7, 9]

The ECMA-C10602RS Delta Servo Motor functions as a high-precision actuator that converts electrical signals into precise mechanical motion. It is specifically designed to provide accurate control of position, speed, and torque in a closed-loop system. [1, 2, 3, 4]

Core Functional Mechanisms

Closed-Loop Feedback: The motor features a 20-bit incremental encoder (delivering 1,280,000 pulses per revolution) that constantly sends position data back to the servo drive. This allows the system to correct errors instantly and maintain exact positioning even under varying loads.
High-Speed Response: It is engineered for rapid acceleration and deceleration, achieving a rated speed of 3,000 RPM to ensure high throughput in automated processes.
Torque Regulation: It provides a steady rated torque of 0.64 Nm, with the ability to reach a peak instantaneous torque of 1.92 Nm for tasks requiring high starting force.
Environmental Durability: Its IP65 rating and built-in oil seal allow it to function reliably in harsh industrial environments with exposure to dust and oil. [1, 2, 3, 4, 5, 6, 7, 8]

Common Industrial Applications

Due to its precise control, this 200W motor is typically used for: [1]

CNC Machinery: Handling axis movement in milling or engraving machines.
Robotics: Powering joints and grippers in robotic arms.
Packaging & Conveyors: Controlling precise stop-start timing on production lines.
Electronic Assembly: Used in pick-and-place machines where high-speed accuracy is critical. [1, 3, 4, 5, 6]

The ECMA-C10602RS Delta servo motor has a net weight of approximately 1.2 kg (2.6 lbs). [1]

If you are calculating shipping or logistics costs, the total shipping weight (including the original box and packaging) is typically around 3.5 kg (7.7 lbs). [1]

Weight Comparison & Dimensions

Net Weight (Motor only): 1.2 kg.
Shipping Weight: 3.5 kg.
Frame Size: 60 mm.
Model Note: Because this specific model (RS) does not include a brake, it is lighter than its "with-brake" counterparts, which typically add about 0.3 kg to 0.5 kg to the total weight. [1, 3, 4]
