Send InquiryECMA-J11020RS Delta Servo Motor 2000W L , Torque Nm - 6.37 , RPM - 3000
Price 41200.0 INR/ Number
MOQ : 1 Number
ECMA-J11020RS Delta Servo Motor 2000W L , Torque Nm - 6.37 , RPM - 3000 Specification
- Sealed Type
- Packing seal
- Product Type
- Servo Motor
- Usage & Applications
- Industrial Machinerry
- Color
- Black and Silver
- Weight
- 6.2 Kilograms (kg)
- Phase
- Three Phase
- Warranty
- 1 Year
- Material
- Aluminum
ECMA-J11020RS Delta Servo Motor 2000W L , Torque Nm - 6.37 , RPM - 3000 Trade Information
- Minimum Order Quantity
- 1 Number
- Delivery Time
- 24 Hours
About ECMA-J11020RS Delta Servo Motor 2000W L , Torque Nm - 6.37 , RPM - 3000
The Delta ECMA-J11020RS is a 2000W high-performance servo motor from the ASDA-A2 series, designed for 400V industrial power systems. [, 2, 3]
Performance Specifications
- Rated Power Output: 2.0 kW (2000 W)
- Rated Torque: 6.37 Nm
- Maximum Peak Torque: 19.11 Nm
- Rated Speed: 3000 RPM
- Maximum Speed: 5000 RPM
- Rated Current: 7.09 A
- Maximum Current: 21.28 A [1, 2, 4, 5]
Electrical & Feedback
- Input Voltage: 400 VAC (3-Phase)
- Encoder Type: 20-bit Incremental (1,280,000 pulses/revolution)
- Resistance: 0.388
- Inertia: 4.45 x 10 kgm (Low Inertia) [1, 4, 5]
Mechanical & Environmental
The physical specifications for the Delta ECMA-J11020RS (2000W model without brake) are as follows:
Dimensions & Weight
| Attribute [1, 2, 3, 4] | Measurement (Inches) | Measurement (Metric) |
|---|---|---|
| Total Length | ~7.56 in | 192 mm |
| Height (Frame) | 3.94 in | 100 mm |
| Width (Frame) | 3.94 in | 100 mm |
| Shaft Diameter | 0.945 in | 24 mm |
| Shaft Length | 2.165 in | 55 mm |
| Net Weight | 13.67 lbs | 6.2 kg |
Key Technical Notes
- Frame Size: This motor features a 100 mm square frame, providing a compact footprint for its 2kW power output.
- Brake Status: The "RS" suffix indicates this model is without a brake. The version with a brake (ECMA-J11020SS) is heavier, weighing approximately 16.53 lbs (7.5 kg).
- Voltage: Part of the 400V VAC class, making it ideal for industrial three-phase systems.
- High-Resolution Feedback: Equipped with a 20-bit incremental encoder, offering 1,280,000 pulses per revolution for high-precision positioning.
- Protection: Rated IP65, ensuring it is dust-tight and protected against water jets. [1, 2, 4, 5]
