ECMA-LA1845RS Delta Servo Motor 4500W H , Torque Nm - 28.65 , RPM - 1500

Name: ECMA-LA1845RS Delta Servo Motor 4500W H , Torque Nm - 28.65 , RPM - 1500
Brand: Corbital Enterprise
Price: 89000.0 INR
Availability: InStock

Price 89000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

ECMA-LA1845RS Delta Servo Motor 4500W H , Torque Nm - 28.65 , RPM - 1500 Specification

Sealed Type
Packing seal

Product Type
Servo Motor

Usage & Applications
Industrial Machinerry

Color
Black and Silver

Weight
27 Kilograms (kg)

Phase
Three Phase

Warranty
1 Year

Material
Aluminum

ECMA-LA1845RS Delta Servo Motor 4500W H , Torque Nm - 28.65 , RPM - 1500 Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About ECMA-LA1845RS Delta Servo Motor 4500W H , Torque Nm - 28.65 , RPM - 1500

The Delta ECMA-LA1845RS is a heavy-duty 4.5kW absolute-type servo motor. As part of the 400V ASDA-A2 series, it is designed to provide massive torque for the largest industrial axes and high-capacity machinery. [1, 2]

Dimensions & Weight

Attribute [1, 2, 3]	Measurement (Inches)	Measurement (Metric)
Total Length	10.04 in	255 mm
Height (Frame)	7.09 in	180 mm
Width (Frame)	7.09 in	180 mm
Shaft Diameter	1.378 in	35 mm
Shaft Length	3.11 in	79 mm
Net Weight	59.52 lbs	27.0 kg

Key Technical Notes

Massive Torque: It delivers a rated torque of 28.65 Nm and can handle a peak torque of up to 71.62 Nm, making it one of the most powerful units in the 180mm frame class.
High Inertia Stability: The "LA" series features Medium-High Inertia. This is essential for stabilizing very heavy mechanical loads, preventing the vibrations that often occur with low-inertia motors at this power level.
17-bit Absolute Encoder: It tracks its position at all times. Even if the machine is moved while the power is off, it "remembers" its exact location, so you never have to perform a "homing" cycle.
Industrial Build: Rated IP65 with a built-in oil seal and keyway, designed to operate reliably in environments with dust, metal shavings, or oil mist.
Brake Status: The "RS" suffix indicates this model is without a brake.
