Send InquiryGD20-2R2G-S2 - INVT VFD 2.2 kW / 3HP 230V
Price 7700.0 INR/ Number
MOQ : 1 Number
GD20-2R2G-S2 - INVT VFD 2.2 kW / 3HP 230V Specification
- Feature
- Advanced Braking
- Mounting Type
- DIN-rail mounting
- IP Rating
- 20
- Humidity %
- 5% to 95%
- Power Rating
- High Performance Vector Control
- Product Type
- VFD
- Application
- Industrial Machinery
- Color
- Black
- Weight
- 1.5 Kilograms (kg)
- Usage & Applications
- Industrial Machinery
- Rated Voltage
- 220V (-15%) to 240V (+10%) Volt (V)
- Warranty
- 1 Year
- Input Voltage
- 220V (-15%) to 240V (+10%) Volt (V)
- Phase
- 3 Phase
- Material
- Plastic
- Rated Current
- 220V (-15%) to 240V (+10%) Volt (v)
- Features
- 220V (-15%) to 240V (+10%)
GD20-2R2G-S2 - INVT VFD 2.2 kW / 3HP 230V Trade Information
- Minimum Order Quantity
- 1 Number
- Delivery Time
- 24 Hours
About GD20-2R2G-S2 - INVT VFD 2.2 kW / 3HP 230V
The is a high-performance, 2.2 kW (3 HP) Variable Frequency Drive (VFD) from the Goodrive20 series. Designed for single-phase 220V240V input, it provides precise 3-phase output control for industrial motors.| Manufacturer: | INVT |
| Series: | GD 20 |
| Model: | GD20-2R2G-S2-EU |
| Application: | general purpose |
| Capacity, kW: | 2,2 |
| Current, : | 11 |
| Main power supply, V: | 230 |
| Phase: | 1 |
| Output frequency, Hz: | 0-400 |
| Enclosure: | IP20 |
| Overload capacity, % per 1 min.: | 150 |
| EMC filter: | optional |
| Braking unit: | built in |
| Analog input: | 1 |
| Digital input: | 5 |
| Analog output: | 2 |
| Digital output: | 1 |
| Relay output: | 2 |
| RS485 (Modbus RTU): | RS485 communication |
| Starting torque: | 150% |
| PID: | + |
| Operation temperature, : | -10.....+50 |
| Dimensions (W x H x D), mm: | - |
| Weight, kg: | - |
Dimensions and Weight (Inches)
This model is built on a slightly larger chassis than the 1 HP version to manage higher power dissipation.
- Height: 7.28 inches (185 mm)
- Width: 3.15 inches (80 mm)
- Depth (Length): 5.53 inches (140.5 mm)
- Weight: Approximately 2.65 lbs to 3.3 lbs (1.2 kg to 1.5 kg)
Key Specifications
- Power Rating: 2.2 kW / 3.0 HP.
- Input Voltage: Single-phase 200V240V AC.
- Output Current: 10.0 Amps.
- Overload Capacity: 150% for 60 seconds; 180% for 10 seconds.
- Control Mode: Sensorless Vector Control (SVC) and V/f Control.
