MADLN15SE - A6SE Panasonic A6 200W Driver

About MADLN15SE - A6SE Panasonic A6 200W Driver

Panasonic MADLN15SE (A6SE 200W Servo Driver)

Panasonic MADLN15SE

---

Electrical & Control Specifications

• Series: MINAS A6 (A6SE type)
• Rated Power: 200 W servo system (used with matching 200W motors)
• Control Type: Position control only
• Input Method: Pulse train (PUL/DIR) only
• Encoder Support: 23-bit high-resolution encoder
• Control Modes: Position control + internal speed mode

---

Physical Dimensions (INCH)

From official Panasonic datasheet:

• Width: 1.57 in (40 mm)
• Height: 5.91 in (150 mm)
• Depth (Length): 5.12 in (130 mm)

---

Weight

• 0.8 kg
• 1.76 lbs

---

Performance

• Frequency response: 3.2 kHz
• Supply voltage: 200240V AC
• Regenerative resistor: External only
• Safety function: Not included

---

Function (Simple Meaning)

This driver is used to:

Control servo motor position accurately using pulse signals from a PLC or controller.

• Converts PLC pulses motor movement
• Uses encoder feedback for accuracy
• Best for simple CNC / automation positioning systems

---

Typical Applications

• CNC machines
• Packaging machines
• Pick-and-place systems
• Basic industrial automation

---

Bottom Line

• 200W servo driver
• Pulse-based position control
• Compact A-frame design
• Lightweight (1.8 lb)
• No advanced networking (like EtherCAT or RTEX)

  Main Function

  This drivers main function is:

  To control a servo motor using pulse signals from a PLC and convert them into precise position control with encoder feedback.

  ---

  Core Functions

  1. Position Control (Primary Function)

  • Works only in pulse train control (PUL/DIR)
  • Converts input pulses into exact motor movement
  • Used for:
    • CNC positioning
    • Indexing systems
    • Simple automation machines

  ---

  2. Encoder Feedback Control

  • Uses 23-bit high-resolution encoder feedback
  • Continuously checks motor position
  • Automatically corrects positioning errors

  ---

  3. Speed Control (Internal)

  • Supports internal speed mode (limited use)
  • Mainly still driven by pulse positioning

  ---

  4. High-Speed Response

  • 3.2 kHz control loop response
  • Fast start/stop motion
  • Smooth and accurate positioning

  ---

  5. PLC Integration

  • Controlled directly by PLC pulse outputs
  • Simple wiring:
    • Pulse
    • Direction
    • Enable

  Very easy to integrate in basic machines

Robust Construction for Industrial Use

Constructed from high-quality aluminum and featuring a packing seal, the MADLN15SE - A6SE Panasonic A6 200W Driver ensures lasting performance under demanding conditions. Its design not only protects the internal components but also supports stable operation within any industrial setup.


Reliable Performance and Power

Supporting three-phase power, this 200W driver delivers consistent and efficient output for industrial machinery. The black and silver finish complements its solid functionality, allowing it to integrate seamlessly with various equipment while maintaining a professional appearance.


Versatile Applications and Easy Sourcing

The driver is tailored for use in industrial machinery, making it a versatile choice for numerous factory and automation processes. With availability through multiple channels such as suppliers, traders, and wholesalers, sourcing this component is straightforward for businesses and end users alike.
