MADLN15SG - A6SG Panasonic A6 200W Driver

About MADLN15SG - A6SG Panasonic A6 200W Driver

Function

This drivers main function is:

To control a servo motor using pulse + communication signals for accurate position control in industrial automation systems.

Core Functions

1. Position Control (Main Function)

• Works mainly in position control mode
• Receives commands from PLC via:
  • Pulse train input
  • RS485 / Modbus communication
• Converts commands into precise motor movement

Used for indexing, CNC, automation machines

2. Encoder Feedback Control

• Uses 23-bit high-resolution encoder feedback
• Continuously corrects motor position
• Ensures high accuracy and repeatability

3. High-Speed Response

• 3.2 kHz control response
• Fast start/stop and smooth motion
• Suitable for high-speed industrial systems

4. PLC / Communication Control

Supports multiple control methods:

• Pulse input (step/dir type)
• RS485 / Modbus communication
• USB setup/monitoring

Flexible integration with PLC systems

5. Auto-Tuning & Stability

• Automatic gain tuning
• Reduces vibration and noise
• Improves stability during load changes

What It Does NOT Do

• No full multifunction control (no torque/speed mode like A6SF)
• No EtherCAT or RTEX network control
• No advanced synchronized multi-axis network

Simple Real-World Meaning

Think of it like:

• Driver = control brain
• Motor = movement
• Encoder = feedback sensor

It mainly tells the motor:
Move to this position accurately using pulses or simple communication.

Typical Applications

• CNC machines
• Packaging machines
• Pick-and-place systems
• Textile machinery
• General industrial automation

Bottom Line

• 200W servo driver
• Position control focused
• Pulse + RS485 communication
• High precision and stable motion
• Not a full multifunction or network (EtherCAT/RTEX) driver

  Dimensions (in inches)

  • Width: 1.57 in (40 mm)
  • Height: 5.91 in (150 mm)
  • Depth (Length): 5.12 in (130 mm)

  (Standard Panasonic A6 A-frame size)

  ---

  Weight

  • 0.8 kg
  • 1.76 lbs

  ---

  Simple Summary

  • Compact servo driver
  • Same size for SE / SG / SF / N / BE A6 A-frame models
  • Lightweight (~1.8 lb)
  • Designed for panel mounting in control cabinets
