MCDLN35BE - E-CAT Panasonic A6 750W Driver

About MCDLN35BE - E-CAT Panasonic A6 750W Driver

Electrical Specifications

• Series: MINAS A6BE
• Motor Power: 750 W
• Supply Voltage: 200230 V AC (1/3 phase)
• Control Type: Servo AC drive
• Communication: EtherCAT high-speed network
• Control Modes: Position / Speed / Torque (via EtherCAT commands)
• Response Speed: 3.2 kHz class (high-speed control)

Main Function (What it does)

1. EtherCAT Network Control (Main Feature)

• Receives commands through EtherCAT real-time network
• Enables very fast communication (industrial automation standard)
• Allows multi-axis synchronization

2. Position Control

• Moves motor to exact commanded positions
• Used in CNC, robotics, pick & place machines

3. Speed Control

• Maintains smooth constant speed under load changes
• Improves motion stability

4. Torque Control

• Controls force output of motor
• Protects machine from overload

5. Closed-Loop Feedback

• Uses encoder feedback from motor
• Continuously corrects position in real time
• Ensures high accuracy and repeatability

System Role

In a servo system:

• Motor = muscle
• Driver (MCDLN35BE) = brain + network controller
• EtherCAT PLC = master controller
• Encoder = feedback sensor

Key Features

• EtherCAT ultra-fast communication
• Multi-axis synchronized motion
• High precision closed-loop control
• 750W industrial servo support
• No STO safety function (basic BE type)

Typical Applications

• CNC machines (multi-axis)
• Industrial robotics
• Semiconductor machines
• Packaging automation
• High-speed pick & place systems

Physical Size (Reference)

• Height: 5.91 in
• Width: 2.56 in
• Depth: 6.69 in
• Weight: 1.6 kg (3.5 lb)

Simple One-Line Meaning

MCDLN35BE is a 750W EtherCAT servo driver that provides ultra-fast, real-time, synchronized motion control for advanced industrial automation systems.

Quick Understanding (Easy)

• SE = basic pulse control
• SG = serial communication
• SF = safety + advanced features
• NE = RTEX network
• BE = EtherCAT high-speed network (most advanced for PLC systems)

  What it actually does

  1. EtherCAT Network Control (Main Function)

  • Receives motion commands through EtherCAT real-time network
  • Enables very fast communication with almost zero delay
  • Supports multi-axis synchronized motion control

  ---

  2. Position Control

  • Moves motor to exact positions
  • Ensures high repeatability and accuracy
  • Used in CNC, robotics, automation systems

  ---

  3. Speed Control

  • Maintains smooth and stable motor speed
  • Automatically adjusts torque under load changes
  • Eliminates vibration and speed fluctuation

  ---

  4. Torque Control

  • Controls motor force output precisely
  • Prevents overload or mechanical damage
  • Useful for pressing, winding, feeding systems

  ---

  5. Closed-Loop Feedback Control

  • Reads encoder feedback from motor (23-bit high resolution)
  • Continuously compares actual vs commanded motion
  • Corrects errors in real time

  ---

  System Role

  In a servo system:

  • Motor = muscle (movement source)
  • Driver (MCDLN35BE) = brain + network controller
  • EtherCAT PLC = master controller
  • Encoder = feedback sensor (accuracy control)

  ---

  Where it is used

  • CNC machines (multi-axis synchronized systems)
  • Industrial robots
  • Semiconductor equipment
  • Packaging machines
  • High-speed automation lines

  ---

  Simple One-Line Meaning

  MCDLN35BE is a 750W EtherCAT servo driver that enables ultra-fast, real-time, and synchronized motion control for advanced industrial automation systems.
