MCDLT35SF - A6SF Panasonic A6 750W Driver

About MCDLT35SF - A6SF Panasonic A6 750W Driver

Electrical Specifications

• Series: MINAS A6SF
• Rated Motor Capacity: 750 W
• Supply Voltage: 200 V AC (single / 3-phase)
• Output Current: ~22 A
• Frequency Response: 3.2 kHz (ultra-fast)

Control & Operation

• Control Modes:
  • Position
  • Speed
  • Torque
  • Full closed-loop control
• Interface:
  • Pulse / Analog input
  • RS232 / RS485
  • Modbus RTU
  • USB (parameter setup)
• Encoder Support:
  23-bit absolute encoder (high precision)

Safety & Features

• Built-in Safety Torque Off (STO)
• Multi-function (A6SF = advanced type)
• 256 internal positioning blocks
• Auto tuning + vibration suppression
• Built-in regenerative resistor

Physical Size (Converted to Inches)

From official dimensions:

• Height: 150 mm 5.91 in
• Width: 65 mm 2.56 in
• Depth: 170 mm 6.69 in

Weight

• Mass: 1.6 kg 3.52 lb

Function (What it does)

This driver acts as the brain + power unit of your servo system:

• Receives motion commands from PLC/CNC
• Converts them into controlled motor current
• Reads encoder feedback from motor
• Corrects position/speed in real time

Result: high precision, smooth, and fast motion control

Typical Applications

• CNC machines
• Robotics
• Packaging machines
• Conveyor automation
• Multi-axis systems

Simple Summary

MCDLT35SF is a high-performance 750W Panasonic A6SF servo driver with full control modes, safety features, and ultra-fast response for precision industrial automation.

Function of Panasonic MCDLT35SF (A6SF 750W Servo Driver)

This device is a servo drive (amplifier/controller). Its main function is to control a 750W Panasonic servo motor with high precision, speed, and safety.

Core Function

It acts as the power brain of the servo system, converting control signals into controlled electrical power for the motor.

What it actually does

1. Position Control

• Moves motor shaft to exact positions
• Ensures precise alignment and repeatability
• Used in CNC, robotics, indexing machines

2. Speed Control

• Maintains commanded speed (smooth rotation)
• Automatically adjusts torque when load changes
• Eliminates speed fluctuation

3. Torque Control

• Controls motor force output precisely
• Prevents overload or mechanical stress
• Used in pressing, tensioning, winding systems

4. Closed-Loop Feedback Control

• Reads encoder feedback from motor (23-bit high resolution)
• Compares actual vs commanded position
• Corrects error in real time (millisecond response)

Safety Function (Important)

• Built-in STO (Safety Torque Off)
• Immediately disables torque in emergency
• Prevents accidental machine movement
• Improves operator safety in industrial systems

Advanced Control Features (A6SF)

• Multi-mode control (position / speed / torque)
• 3.2 kHz ultra-fast response
• Auto tuning for smooth performance
• Vibration suppression algorithms
• Multi-axis synchronization support

Where it is used

• CNC machines (milling, turning)
• Industrial robots
• Packaging and filling machines
• Conveyor and automation lines
• Precision assembly systems

Simple One-Line Meaning

This drivers function is to precisely control a 750W servo motor by managing its position, speed, and torque using real-time feedback and safety protection.
