MD200S1.5 - 2 hp - MD200 - 1 Phase - Inovance Ac Drive

Name: MD200S1.5 - 2 hp - MD200 - 1 Phase - Inovance Ac Drive
Brand: Corbital Enterprise
Price: 9000.0 INR
Availability: InStock

Price 9000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

MD200S1.5 - 2 hp - MD200 - 1 Phase - Inovance Ac Drive Specification

IP Rating
20

Product Type
VFD

Application
Industrial Machinerry

Color
Gray or Black

Usage & Applications
Industrial Machinerry

Weight
1.3 Kilograms (kg)

Warranty
1 Year

Phase
1 Phase

Material
Polycarbonate

MD200S1.5 - 2 hp - MD200 - 1 Phase - Inovance Ac Drive Trade Information

Minimum Order Quantity
1 Number

Delivery Time
24 Hours

About MD200S1.5 - 2 hp - MD200 - 1 Phase - Inovance Ac Drive

The Inovance MD200S1.5 (2 HP) shares the same compact "book-style" frame as the 1 HP model, allowing for consistent panel layouts across different power ratings. It provides 8.0 A of output current to handle larger motor loads while maintaining a slim profile. [1, 2]

Dimensions & Weight (2 HP Model)

Specification [1, 2]	Metric Value	Inch Value (Approx.)
Height (H1)	180 mm	7.09 in
Width (W)	75 mm	2.95 in
Depth (D)	145 mm	5.71 in
Weight	1.3 kg	2.87 lbs

Note: While the unit itself is 1.3 kg, the shipping weight with packaging typically reaches around 1.8 kg (3.97 lbs). [1]

Technical Differences (vs. 1 HP)

Rated Power: 1.5 kW (2 HP) vs 0.75 kW (1 HP).
Output Current: Increased to 8.0 A (the 1 HP model is 4.6 A).
Input Current: 18.0 A single-phase input requirement.
Cooling: This model is fan-cooled to manage the higher heat output from the 2 HP rating. [1, 2, 3, 4, 5]

The Inovance MD200 series functions as an open-loop, general-purpose AC drive designed to control the speed and torque of asynchronous motors. It is widely used in industrial automation for its high power density and reliable performance in compact spaces. [1, 2]

Core Control Functions

Control Modes: Supports both Open-loop V/F control and Sensorless Vector Control (SVC).
High Starting Torque: Provides up to 150% torque at 3 Hz in SVC mode, making it suitable for heavy-start applications.
Torque Management: Features Automatic Torque Boost and Slip Compensation to maintain stable motor performance under varying loads.
Braking: Includes a built-in dynamic braking unit and supports variable DC-injection braking for controlled deceleration.
Speed Ramping: Equipped with 2 independent S-ramps for smooth acceleration and deceleration. [1, 2, 3]

Input/Output & Communication [1]

Programmable I/O: Offers flexible digital and analog connections, including 4 programmable digital inputs (DI1-DI4) and a relay output.
Analog Interface: Includes a 0-10 V analog input (AI) for speed reference and a 0-10 V analog output (AO) for monitoring.
Protocols: Standard Modbus RTU communication is built-in for PLC or SCADA integration, with optional support for CANlink. [1, 2, 5]

Protection & Diagnostics

Environmental Protection: Features Class 2 conformal coating, making it resistant to humidity and dust pollution (3C2 and 3S2 environments).
EMC Filtering: Contains an internal EMC filter (Category C3) to minimize electromagnetic interference.
Diagnostics: Provides comprehensive trip diagnostics to help identify and troubleshoot faults quickly.
