Price 14200.0 INR/ Number

MOQ : 1 Number

MD200T3.7B - 5 HP - MD200 - 3 Phase - Inovance Ac Drive Specification

  • IP Rating
  • 20
  • Product Type
  • VFD
  • Application
  • Industrial Machinerry
  • Color
  • Gray or Black
  • Weight
  • 1.3 Kilograms (kg)
  • Usage & Applications
  • Industrial Machinerry
  • Warranty
  • 1 Year
  • Phase
  • 3 Phase
  • Material
  • Polycarbonate


MD200T3.7B - 5 HP - MD200 - 3 Phase - Inovance Ac Drive Trade Information

  • Minimum Order Quantity
  • 1 Number
  • Delivery Time
  • 24 Hours


About MD200T3.7B - 5 HP - MD200 - 3 Phase - Inovance Ac Drive

The Inovance MD200T3.7B is the high-power 5 HP (3.7 kW) 3-phase model in the MD200 series. While it handles significantly more power, it maintains the same compact "book-style" design found across the series, allowing for high power density in small control panels.

Dimensions & Weight
Like other models in this chassis group, its dimensions are standardized for easy panel layout. [1]
Dimension Metric (mm) Imperial (Inches)
Height 180 mm 7.09 in
Width 75 mm 2.95 in
Depth 145 mm 5.71 in
Weight 1.3 kg 2.87 lbs
Key Technical Specifications
  • Rated Power: 3.7 kW (5 HP).
  • Input Voltage: 3-Phase 380 V to 480 VAC.
  • Rated Output Current: 9.5 A.
  • Overload Capacity: 150% for 60 seconds; 180% for 3 seconds.
  • Braking: Includes a built-in dynamic braking unit (chopper) for high-inertia stops.
  • Cooling: Forced-air cooled via an internal fan. [1, 2, 4, 5]
Functions & Features
  • Control Modes: Supports both Sensorless Vector Control (SVC) for high torque at low speeds and standard V/F control.
  • Reliability: PCBs are protected with a Class 2 conformal coating, making the unit resistant to moisture and industrial dust (3C2 and 3S2 environments).
  • Communication: Standard Modbus-RTU (RS485) and optional CANlink for system integration.
  • Diagnostics: Features comprehensive trip diagnostics for simplified maintenance. [1]
